M1022 crankshaft journal grinding machine
- 300 Set / Sets per Month
- Shanghai or China any port OHA M1022 crankshaft journal grinding machine
- T/T L/C D/P D/A Credit Card PayPal
-
Second-hand sweeper second-hand mobile phone curved glass sweeper tablet computer curved glass sweeper
-
Automatic Ultrafine Powder Grinder with Ceramic Mortar
-
Automatic Powder Grinder with Ceramic Mortar
-
Pneumatically-lifted Laboratory Grinder (Special grinding equipment for scientific research in Colleges and Universities)
-
Pneumatically-lifted Grinder with Double Pestle and Ceramic Mortar (manual discharging)
-
Pneumatically-lifted Grinder with Ceramic Mortar (Large grinder for chemical material and new material)
Product Details
| Condition: | New | Type: | Surface Grinding Machine | CNC or Not: | CNC |
| Max. Grinding Diameter: | 100mm | Max. Grinding Length: | 560, 560mm | Place of Origin: | Shanghai, China |
| Brand Name: | OHA M1022 crankshaft journal grinding machine, OHA M1022 crankshaft journal grinding machine | Model Number: | M1022 | Voltage: | 380V 50Hz |
| Power(W): | 1.5w | Dimension(L*W*H): | 1280x1250x1880mm | Weight: | 1100kg |
| Certification: | ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
OHA M1022 crankshaft journal grinding machine
Characteristics of M1022 crankshaft journal grinding machine
a. Spindle adopts ultra precision P4 ball bearing,after measuring pre strict pressure,assembled in the greenhouse,and equipped with a completely waterproof mazy design,in order to ensure the service life abd tge grinding of bearing surface roughness which marching with ball screw.
b. It has the advantages of compact structure,easy to operate.
c. A longitudinal guide rail worktable adopts rolling guide,rope wheel traction,light and flexible.
Details photos:
Technical Specifications for M1022:
| Technical Parameters | Unit | M1022 | M820 | M618 |
| Table Max.cutting area(LXWXH) | mm | 560x250x490 | 520x220x490 | 500x190x335 |
| Working Table Movement Max.Grinding Length | mm | 560 | 520 | 500 |
| Working Table Movement Max.Grinding Width | mm | 250 | 220 | 190 |
| Distance From Table to spindle center | mm | 490 | 490 | 335 |
| Slide Way | V-type double rail with steel-ball | V-TYPE | V-TYPE | |
| Max. work load | kg | 250 | 200 | 200 |
| Table size | mm | 500x250 | 480x200 | 460x180 |
| Number of T-Slot | mmxn | 14x1 | 14x1 | 14x1 |
| Table Speed | m/min | 3-23 | 3-23 | 3-23 |
| Front and rear wheel feed | mm | 0.02/graduation 4/revolution | 0.02/graduation 2.5/revolution | 0.02/graduation 2.5/revolution |
| On the hand wheel feed | mm | 0.01/graduation 2/revolution | 0.01/graduation 1.25/revolution | 0.01/graduation 1.25/revolution |
| Wheel Size(Diaxwidthxbore) | mm | 200x20x31.75 | 200x20x31.75 | 180x13x31.75 |
| Spindle speed 50hz | rpm | 2850 | 2850 | 2850 |
| Spindle speed Variable frequency motor | rpm | 0-6000 | 0-6000 | 0-6000 |
| Spindle motor | kw | 1.5 | 1.5 | 1.1 |
| Cooling pump | kw | 0.4 | 0.4 | 0.4 |
| Packing size(LxWxH) | mm | 1280x1250x1880 | 1260x1140x1760 | 1240x1080x1680 |
Packing Details:
OHA Machinery Group Advantage:
1. Competitive price: It is can meet your budget and best-selling business very well.
2. OEM Accepted: We can produce any your request design.
3. Good Service: We treat clients as friends.
4. Good Quality: We have strict quality control system. Good reputation in the market.
5. Fast & Delivery: We have big discount from forwarder (Long Contract).
Innovation for OHA Machinery Group
Quality & Service: In OHA, our #1 priority has always been providing our clients with great quality products and superior customer service. |
Quick lead Time: We’re dedicated to providing the quickest turn-around times and work very hard to ensure that all of your deadlines are met |
Unbeatable Prices: We continuously strive to find ways of reducing our production costs, and passing the saving over to you! |
Brand Awareness: The goal of any strong brand is achieve a level of awareness that instills the idea of quality and value into all of your potential customers. |
Special Offers:In order to maintain our competitive edge, we are constantly running special offers on our Best –selling press brake, forging equipment goods and design services. Contact our sales term to see how we can help you save a lot of money. |
General order Information:
We take great pride in our work and in the wide variety of products that we offer. We are experienced in servicing the Southeast Asia market, South America, European market and Africa market. Please be aware that our production lead times depend on specific items and item quantities.
OHA Machinery Group Show:
OHA INDUSTRY & TRADE (SHANGHAI) CO., LTD. is a leading Chinese sheet metal processing machinery and construction machinery exporter and importer, located in the Shanghai Free trade zone.
We faithfully enforce ISO9001:2000 and CE,SGS, BV certificate to guarantee that every product meets international standards. With a professional R&D team, skillful workers and a complete quality control system, we won the good reputation from reliable quality, competitive price and excellent after-sales service. Our export revenue increases constantly every year, and our products have already entered nearly 100 countries across the continents of South America, Africa, Middle East, Australia, Russia, Middle Asia, South Asia, Southeast Asia, and East Europe. We sincerely hope to cooperate, develop together and build a good future with you. Please feel free to contact us for more information about our products and services.
OHA Machinery Group CE,ISO,Patent:
Why Choose Us?
- China Famous Brand
- National inspection -free products
- CE,CQC,SGS, GOST etc
- A+ Grade Service Supplier
- Professional more than10 years manufacture and trading
- Actual Machinery Picture
- Feasible Solutions
- Technology Driven Products
- Affordable and Cost Effective
- Professional Experienced Staff
- Customer Satisfaction
For any questions or information, welcome to contact with us. Thanks!
