Automatic Heat Tunnel Shrink Wrapping Machine
US$ 10,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
Other, Plywood Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Letter Sealing Machine For Letter,Portable Plastic Sealing Machine,Paper Sealing Machine For PaperUS$ 1,000 - 2,000MOQ: 1 Set -
Custom Made Mattress Sealing And Shrink Wrapping Machine,Mattress Packing MachineNegotiableMOQ: 1 Set
-
Spring Water Bottle Sealing Machine,Spring Water Bottle Sealing Sleeve Shrink Packing MachineUS$ 4,000 - 8,000MOQ: 1 Set
-
Mineral Water Bottle Sealing Machine,Mineral Water Bottle Sealing Sleeve Shrink Packing MachineUS$ 4,000 - 8,000MOQ: 1 Set
-
Vessel Sealing Machine,Vessel Sealer,Vessel Sealing EquipmentUS$ 1,000 - 2,000MOQ: 1 Set
Condition
New
Application
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type
Other, Plywood Case
Packaging Material
Plastic
Automatic Grade
Automatic
Driven Type
Electric
Voltage
220 V & 380 V
Power
18 KW
Place of Origin
Fujian, China
Brand Name
Sheng Zhou
Model Number
SZ LSS5560
Dimension(L*W*H)
3300 x 1900 x 2900 MM
Weight
500 KGS
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Automatic Heat Tunnel Shrink Wrapping Machine
Features
- Photocell product sensors
- Operates with all shrink film types
- Full safety features on seal head
- PLC controlled electrical system
- Adjustable package transfer area
- Easy film loading and changeover
- Rugged construction for low maintenance
- Adjustable roller perforator air venting device
- Variable speed infeed and discharge conveyors
- Very easy to use and operator friendly interface
- Internal vacuum scrap removal system with manifold
- Heavy duty welded structural tube steel construction
- Micro-Processor controlled low voltage sealing system
- Variable speed film unwide with adjustable inverting head
- Speeds up to 30 packages per minute (varies with package size)
- Heavy duty locking casters and adjustable legs for high mobility and re-positioning
- Incorporated by one L Type Sealer and one Shrink Tunnel, both machines can be separated and work alone when necessary
- One time investment for 2 machines offering 3 packaging solutions in one step - film sealing only, shrinking only or sealing & shrinking
Samples
hot sale high speed fully automatic film shrink wrapping machine
Specification
Shrink Tunnel
Chamber Size |
L1000 x W450 x H200 MM |
Package Size |
Max. W350 x H150 MM |
Temperature |
Max. 200 oC adjustable |
Conveyor Speed |
Max. 10 M/ MM |
Conveyor Load |
Max. 15 KGS |
Power Supply |
380 V, 50 HZ, 3 PH |
Power Consumption |
7.5 KW |
Net Weight |
90 KGS |
Overall Size |
L1500 x W700 x H1350 MM |
Shipping Size |
L1580 x W810 x H1400 MM |
L Type Sealing Machine
Efficiency |
30 Pcs Per Min Depends On Products Size |
Sealing Size |
Max. L630x W520 MM adjustable |
Packaging Size |
L(60-560) x W(60-430) x H(10-160) MM |
Film Width |
Max.26" |
Power Supply |
220 V, 50 HZ |
Power Consumption |
3.0 KW |
Air Consumption |
0.6 MPA |
Overall Size |
L1767 x W1205 x H1570 MM |
Net Weight |
300 KGS |
hot sale high speed fully automatic film shrink wrapping machine
Packing INFO
