Product Details
| Place of Origin: | Guangdong, China | Brand Name: | HIOSO | Model Number: | Foway1310TFS-H |
Product Description
8FE RJ45+2GE SFP Uplink 10 Ports Industrial 100/1000M Ethernet Switch
Overview
HiOSO FOWAY1310TFS-H is unmanaged 10 ports industrial node type fiber switch, with 8 ports 10/100M adaptive RJ45 ports and 2 1000M SFP uplink port/node port, supports SFP modules hot plug, and supports to work with fiber switches, fiber converters and other devices witch fiber ports, support HD video flow transmission, applies to security system, electric system, traffic system requirements.
Character
Support maximum 8 100M RJ45 ports and 2 1000M SFP port/node port
Support to establish Gigabit fiber node network
Support SFP modules hot plug
Support 100M port and 1000M port full rate, full duplex non-blocking forwarding
Support 8K MAC learning, 1Mbit storage and forward cache space
Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
Support to choose one side with fixed metal casing, external power design, better for heat dissipating and installation
Technical Specification
Parameter | Specification |
Standard | IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T ,IEEE802.3z 1000Base-SX/LX Gigabit ethernet, IEEE802.3x Flow control, IEEE802.1q VLAN, IEEE802.1p QoS, IEEE802.1d Spanning Tree |
Wavelength | SFP module: 850nm/1310nm/1490nm/1550nm |
Distance | 1000M SFP module, Multi-mode: 220m(fiber 62.5/125μm)/550m (fiber 50/125μm) Single-mode: 10/20/40/60/80/100/120Km Single-fiber Single-mode: 10/20/40/60/80/100/120Km |
Port | 8 100M RJ45 ports: 10/100Mbps 2 1000M SFP ports: 1 Gbps,1000M SFP |
MAC address | 8K |
Buffer memory space | 1Mbit |
Bit error rate | <1/1000000000 |
MTBF | 100000 hours |
Power | DC12V/1A |
Power consumption | 6W |
Working temperature | -10~60℃ or -40~75℃ |
Storage temperature | -40~80℃ |
Humidity | 5%~90% non-condensing |
Dimension | 28mm (H)×193mm(W)×119mm (D) |
Order Information
NO | Type | Management | Ports | Working temperature |
1 | Foway1310TFS-H | NO | 8 100M RJ45 ports +2 Gigabit SFP uplink/node port | -10~60℃ |
2 | Foway1310TFS-HT | NO | 8 100M RJ45 ports +2 Gigabit SFP uplink/node port | -40~75℃ |
