Help CenterSpecially Produce Cnc Milling Machine Frame SW-DX6060
Related Products
-
Specially Produce Cnc Engraving Milling Machine Frame SW-DX6060NegotiableMOQ: 1 Set -
Body of Engrave Milling Machine SW-DX7070NegotiableMOQ: 1 Set
-
Fuselage of Engrave Miller SW-DX7070NegotiableMOQ: 1 Set
-
Frame of Engraving and Milling Machine SW-DX7070NegotiableMOQ: 1 Set
-
Body of Engraving and Milling Machine SW-DX6060NegotiableMOQ: 1 Set
Specifications
cnc milling machine frametable:550x650mm
travel:600x600x250mm
spindle speed:600-24000rpm
working load:200kg
cnc milling machine frame
cnc machine frame
milling machine frame
welcome to visit our website,the specification data of specially produce cnc milling machine frame SW-DX6060 is as followed,if you need other information of our machine,please contact me freely or visit our factory by feild trip.
One.features of specially produce specially produce cnc milling machine frame SW-DX6060
1.each machine body have been debugged by system,and every oil circuit point ,beat of ballscrew,bearing warming,noise and geometric accuracy by tug strictly.
2.The performance of the machine body is steay,and our machine is good at long time machining and guarantee the quality of the products meanwhile.
3.Positioning precision is ±0.01mm and resetting precision is ±0.003mm.
two.Specifications of specially produce cnc milling machine frame SW-DX6060
Item |
Unit |
SW-DX6060 |
Table size |
mm |
550×650 |
Travel(X/Y/Z) |
mm |
600/600/250 |
Max height of workpiece |
mm |
400 |
Max weight permissible |
kg |
300 |
Precision |
mm |
0.002(Automatic) |
Positioning |
mm |
0.01/300 |
Repeating |
mm |
0.005 |
Uprightness of X,Y axis |
mm |
0.015/300 |
three.Main configuration of specially produce specially produce cnc milling machine frame SW-DX6060:
|
name |
Brand/specification |
note |
1 |
Coupling Shaft |
Mikipulley(Japan) |
|
2 |
Shield Of Y-axis |
Domestic |
Stainless Steel |
3 |
Ball screw of three axles |
C3 level double nuts ball screw of 3 axis |
|
4 |
Beeline rail of three axles |
High Precision beeline guide of HIWIN (Taiwan) |
|
5 |
Lubrication way |
Nanjing(Jiangsu) |
Centralized Oiling (include liduid level,pressure alarm) |
6 |
Bearing |
NSK(Japan) or NACHI |
P4 level of high accurate match bearings |
7 |
Accurate Round Nuts |
taiwan |
|
8 |
the main motor seat
|
|
bore diameter can decided by customer |
7 |
Whole Machine Painting |
Plastic Spraying |
|
9 |
Resin sand casting of machine body |
|
OME of DMG |
s of specially produce specially produce cnc milling machine frame SW-DX6060:
five.Production capacity
|
Company Brief Nantong sunway technology company is established in 2000year.We are the professional manufacturer of vertical machining center,cnc gantry milling machine,cnc engraving and milling machine,electrical discharge machine and so on.Our machine have been exported to Europe,America,Southeast Asia,Korea and many foreign countries,we also supply OEM service. |
|
|
Assembly shop of vertical machining center We follow strict assembly technique after we check each parts are eligible.
|
|
|
Assembly shop of cnc engraving and milling machine
|
|
|
Complete engraving and milling machine After finishing leave factory testing,we will use waterproof and anti extrusion to protect the machine’s safety during transportation. |
|
|
Small Gantry milling machine We could supply OEM service and custom design service. |
|
|
Electrical discharge machine which will be exported to SAMSUNG,Korea Our electrical discharge machine have exported to SAMSUNG(Korea), MAKINO(Japan),Brazil,Argentina,Mexico,Turkey.All machines runs well,they have not broken till now,we always trust”no maintenance service is the best service”. |
|
|
Metal plate Our metal plate use laser cutting and international advanced welding technique,while supply elegant appearance for surface of machine. |
|
|
Casting Our casting are made for resin sand,grade HT250,we are the sole casting factory which exported to DMG(German) in our domestic and meanwhile we are the supplier of Foxconn(supplier of Apple Inc) and supply 6000 sets casting to Foxconn. |
|
|
Gantry machining center Using famouse brand gantry machining center,is the key point to guarantee the precisio and surface finishment of machining face. |
|
|
Detection of assembling In strict accordance with German standard to do precision detection on our linear rail,ball screw,table surface, to guarantee the integral precision of machine. |
|
|
Precision detection
|
|
|
Laser inspection equipment Owning the advanced laser inspection equipment,which is made in USA,are stable guarantees of improving the quality and precision of machines.
|
|
