100M Ethernet Fiber Optical Media Converter

Name: 100M Ethernet Fiber Optical Media Converter
Brand: HiOSO
SKU: 117145285
Availability: InStock

100M Ethernet Fiber Optical Media Converter thumbnail-1

100M Ethernet Fiber Optical Media Converter photo-1

US$ 1 - 200 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

HiOSO

Model Number:

FC610A

Contact Supplier Request Quote Chat Now

Hioso Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name HiOSO

Model Number FC610A

Profile

HiOSO FC610A is a kind of 10/100Mbps adaptive fast Ethernet fiber converter (also called optical-to-electric medium converter), which can implement mutual conversion between 10Base-T/100Base-TX twisted pair electrical signal and 100Base-FX optical signal. This type of fiber converter can extend the transmission distance of a network from 100m over copper wires to 120Km (single-mode full duplex).

This type of fiber converter supports two different types of network connection media: 10/100Base-TX and 100Base-FX. With the application of the switching technology and the storing & forwarding technology, the converter can implement data transmission between two types of network connection media.

This kind of converter supports transmission in dual-fiber multi-mode, dual-fiber single-mode and single-fiber single-mode fibers.

Features

Adaptive 10Mbps and 100Mbps environments, for the convenience of network upgrading;
Efficient built-in switching core, to implement flow control and reduce broadcast packets;
Supporting full-duplex and semi-duplex transmission modes and capable of automatic negotiation;
Supporting automatic crossing of twisted pair ports, for the convenience of system debugging and installation;
Supporting the transmission of extra-long packets (with the maximum length of 1552 bytes);
Supporting the transmission of extra-long packets over VLAN:
Supporting Quality of Service (QoS) and ensuring transmission of VoIP packets;
Supporting Spanning Tree Protocol (STP) to form a redundant network;
Low power consumption, low heat dissipation and capable of stable operation for a long period of time;
Supporting multiple types of fiber ports, such as dual-fiber multi-modedual-fiber single-mode and single-fiber single-mode, to satisfy the extended requirements of users.

Application
10/100Mbps fast Ethernet long-distance transmission network

Technical Specifications

Parameters	Specifications
Access mode	10/100Mbps
Standard	IEEE802.3 10Base-T Ethernet,IEEE802.3u,100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS,IEEE802.1d Spanning Tree
Wavelength	850nm/1310nm/1550nm
Transmission distance	Dual-fiber multi-mode: 2Km, dual-fiber single-mode: 25/40/60/80/100/120Km, single-fiber single-mode: 25/40/60/80/100Km Category-5 twisted pairs: 100m
Port	One RJ45 port: Connected to STP/UTP category-5 twisted pairs One fiber port: Multi-mode SC or ST (fiber size: 50,62.5/125μm) Single mode SC/FC fiber port (fiber size: 9/125μm) Single-fiber single-mode SC/FC fiber port (fiber size: 9/125μm)
Conversion mode	Medium conversion, storing and forwarding
MAC address table	I K
Buffer space	1Mbit
Flow control	Full duplex state: flow control; half-duplex state: back pressure mode
Delay	9.6μs
Bit error rate	<1/1000000000
MTBF	100,000 hours
LED	POWER (power), FX LINK/ACT (fiber link/action) FDX (FX full-duplex mode), TXLINK/ACT (twisted pair link/action) TX 100 (twisted pair, transmission rate: 100M)
Power	DC5V 1A (external), AC220 0.5A/DC-48 (built-in)
Power consumption	3W
Operating temperature	-10~55°C
Operating humidity	5%~90%
Storage temperature	-40~70°C
Storage humidity	5%~90% (non-condensing)
Dimensions	24mm(H)59mm(W)98mm(D) (height * width * depth) (external power) 26mm(H)85mm(W)135mm(D) (height * width * depth) (built-in power) 110mm(H)22mm(W)81mm(D) /height * width * depth (module card)
