500w 36v 12ah Middle Motor Mountain Electric Bicycle

US$ 500 - 600 MOQ: 1 Piece

Key Specifications

Wattage:

351 - 500w

Voltage:

36V

Power Supply:

Lithium Battery

Yongkang Mars Vehicle Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo

Delivery Detail:

Delivery time depends on order quantity.

Wattage 351 - 500w

Voltage 36V

Power Supply Lithium Battery

Wheel Size Other, 26“

Motor Brushless

Certification CE

Frame Material Aluminum Alloy

Foldable No

Max Speed Other, <30km/h

Place of Origin Zhejiang, China

Brand Name HXR

Model Number TDE17Z

Frame:	Al Alloy 6061 T6
Tyres:	26"×1.95", puncture resistant K-shield (CST)
Rim:	Al Alloy twin wall and CNC side wal(ALEX)
Spokes:	13g steel/stainless (SHUNDELI)
Brakes:	Front:V-brakes,rear:V-brakes (WINZIP)
Gears:	SHIMANO 7 speed gears TX-55
Front fork:	Suspension, Al alloy double crown(ZOOM) Option:RST
Handle bars:	Al Alloy (ZOOM)
Head set:	Water proof headset (NECO)
Chainguard:	ABS (Yongfang)
Mudguard:	VP (Bikemen)
Chainwheel:	Steel 45T, Al alloy crank
Chain:	Rust resistant chain (KMC)
Stander:	Al alloy side stander (GS)
Saddle :	VELO
Seat Post :	Al alloy with suspension (ZOOM)
Pedal	WELLGO

Motor:	500W High Speed Brushless Gear DC hub motor black mat(Xiongfeng)
Display:	LED Option:LCD
Controller:	Intelligent brushless controller (Kunteng)
	Pedaling Run/Pedaling-Electric Assist Run
	Option: Pure Electric Run Model
	Overload protection ,Low voltage protection
Battery :	Option: 36v 10Ah li-on battery
Charger :	100-240V 50-60HZ,1.8 amps smart charger. Charge time 4-6 hours
Performance	8 hours
Max Speed :	≤38Km/h
Range:(36v 10ah 65KG)	e-bike mode 32-40km,
	Pedaling assist mode 50-55km
Load capacity:	125KG
N.W./G.W. :	24.5/29 kgs(with battery)
Carton Size :	1480X250X840 mm
Capability :	88pcs/20' 148pcs/40' 190pcs/40' HQ
