25mm Manual Vertical Z-axis Stage
US$ 1 - 200
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
LS
Model Number:
LSSS-25JL
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
40mm Travel Gear Rack Manual Positioning StageNegotiableMOQ: 1 Piece -
Motorized Rotary Positioner LSDH-400WS-HNegotiableMOQ: 1 Piece
-
LSSP-25XVY(R/L) Three Modes Ball Bearing Linear StageNegotiableMOQ: 1 Piece
-
LSKZB Motorized Stepper Motor ControllerNegotiableMOQ: 10 Pieces
-
LSSP-X-13VZ-03 Precision Positioning StageUS$ 1 - 100MOQ: 1 Piece
Place of Origin
Jiangxi, China
Brand Name
LS
Model Number
LSSS-25JL
25mm Manual Vertical Z-axis stage LSSS-25JL
1.Guide rail is cross roller matched with V steel guide rail, can achieve higher precision and large load capacity.
2.With the helical gear and rack driving, when loaded with large capacity, it also motions comfortably and stably.
3.Readings on the vernier caliper are adjusted quantitatively in all vertical
4.It ‘s safe and reliable with Locking positioning screws.
Travel |
25mm |
Resolution |
0.01mm |
Table top size |
70×70mm |
Load capacity |
10 kg |
Weight |
0.9 kg |
Initial Altitude |
103.5mm |
