Precision Multi-dimension Positioning Stage HTIMS302XYR
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
Liansheng Optics
Model Number:
HTIMS302XYR
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Shenzhen or other China major port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Precision XYZ Linear Translation Positioning Motion Stage HTIMS304RNegotiableMOQ: 1 Piece -
Precision Linear Translation Stage HTDT15NegotiableMOQ: 1 Piece
-
Optical Lens Holder HTL5X-25NegotiableMOQ: 1 Piece
-
High Precision Manual Vertical Translation Lab Jack HTVS SeriesNegotiableMOQ: 1 Piece
-
XYZ Precision Micrometer Manual Multi-Axis Positioning Linear Translation Stage HTIMS502(R)NegotiableMOQ: 1 Piece
Place of Origin
Jiangxi, China
Brand Name
Liansheng Optics
Model Number
HTIMS302XYR
Precision Multi-dimension Positioning Stage HTIMS302XYR
1. Multi-dimension translation with compact design.
2. Fine grinded steel guide rails with supplementary linear ball screw bearing provides high accuracy.
3. Right and left handed operating available.
4. Micrometer drive, spring return without backlashes.
| Adjustment Range(X Y): | 13mm |
| Min Scale Reading(Z) | 1° |
| Min Scale Reading: | 0.005mm |
| Senstivity( X Y): | 0.002mm |
| Platform Diameter: | 106mm |
| Load Capacity: | 4kg(0.8kg in vertical direction) |
| Weight: | 0.75kg |
| Surface Treatment: | Anodized;Chinese Red |
