Home > Agriculture & Food > Protected Horticulture > Plastic Greenhouse > 3-1500t Hopper Bottom Silos for Storing

3-1500t Hopper Bottom Silos for Storing

US$ 1,000 - 10,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Size:

Large

Model Number:

Place of Origin:

Liaoning, China

Contact Supplier Request Quote Chat Now

Yingkou Minzheng Plastic Machinery Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Size Large

Model Number JZ

Place of Origin Liaoning, China

Brand Name JZ

Specifications

silo:Provide galvanized silo with virous capacity ranging from 5t to 10000t ,low price,high quality.

The advanteges of ZIBO BODA STEEL SILO CO., LTD:

1.Over 15 years Steel Silo Engineering experience and rich expertise;
2. Steel Silo Wide storing capacity range, 5~10000 tons, the silo’s diameter ranges from1.8 to 32 meters;
3. Effective global Steel Silo sales & services network;
4. Steel Silo For storing wheat, feedstuff, corn, sawdust, wooden chips, PE pellets, rice etc., large capacity;

5. Preferable price with best quality; 275g/m2, 350g/m2, 450g/m2 zinc-coated silos are available;
6. BODA company can supply foundation design, steel structure design and production, lifting system, conveying

system, cleaning system, drying system, fluidization system, temperature system, full measuring system, fumigation

system, ventilation system, automatic controlling system and other professional services in installing or debugging for

silos and handling equipments ect. up to personnel training and so on.

General Introduction of BODA Service scope:

1. Steel storage silo(roof degree:30): 5t-10000t. There're roof vents, manhole, outside ladders, inside ladders, square silo door and platform. The silo roof

and body sheets sheets are made of hot dip galvanized sheets in good quality, zinc plated by 275g/m2.

2. Blocked and rotary level indicator: to indicate if the silo is full or empty

3. Ventilation system: include fan, ventilation pipes/planks, circular ducts(this part could be painted or galvanized, for hopper bottom sheets only)

4. Temperature monitoring system: to indicate if the material stored in a safety condition. Include temperature cables,

sensors and thermoscope

5. Roof electric valve: painted or galvanized

6. Discharge manual valve: painted or galvanized

7. Roof catwalk: be suitable for above two silos discharged by roof conveyor. Painted or galvanized. Flow pipes:

usually for one or two silos

8. Roof catwalk support:Assembly, painted or hot dip galvanized

9. Conveying system: 10t-150t/h. roof chain conveyor or discharge chain

conveyor(discharge belt conveyor is for your choice), painted or galvanized

10. Elevator: 10t-150t/h. Always equipped with vertical tower to support elevator, also convenient for people climbing up for

equipments’ maintenance.

11. Cleaning system and dust collector system: to remove the impurities away.

12. Drying system: to dry wet material into a safety stored moisture.

13. Electricity controlling system: Could be supplied by BODA or users buy it themselves. Electricity in China:

380V,3phase-4wire. Different requirement from customers can be satisfied. If we offer this part, we take charge of control panel

and related load ancillary equipments only, power systems shall be provided by the users

14. Foundation: Foundation and baseplates shall be made by users. Boda will supply baseplates distribution

drawings.

15. Installation: The company has dedicated professional engineering team and there are installation engineers and

technicians, security supervisors, quality inspectors in each team; Two (2) forms of installation are for your reference

both in domestic and foreign. For one thing, we are in charge of the whole project (turnkey project), for the other,

we are to guide the installation. That is Boda company will send 1-2 engineering and technical personnel on-site for guidance, so the user shall install silos by themselves using the installation tool user-owned.
