Non-conductive Gray Mastic Sealing Tape /excellent Electrical Mastic Sealing Tape

MAST

Non-conductive gray mastic Sealing Tape /excellent electrical mastic sealing tape

Product description

Mastic sealing tape is a gray mastic tape. It is non-conductive, has good compression qualities and excellent electrical properties.

Applications

It can be wrapped, stretched or molded around irregular shapes for quick, smooth insulation build-up. Use it to insulate connections up to 600 volts and make a moisture seal at ground wire exits in high-voltage spliecs.

Performance characteristics

Property                                                    Typical Value                            Test Method

Specific Gravity(g/cm3)                           1.25                                           GB/T 533-1991

Cone Penetration(16°C,1/10mm)              62                                              GB/T 4509-1998

Water Absorption(%)                              0.06                                            GB/T 8810-2005

Flow at Elevated Temperatures              No flow, sag or bleed at 49°C    GB/T 17875-1999

Low Temperature Flexibility                   No cracks or loss of adhesion    GB/T 1682-1994

Adhesion to Steel(N/mm)                        3.2                                              GB/T 2790-1995

Volume Resistivity(Ω·cm)                      10¹⁴                                            GB/T 1692-1992

Application Temperature(°C)                4~38

Service Temperature(°C)                       -40~60

Ordering information

Mastic sealing tape is available in the following roll sizes:

3mm×38mm×1.5m

3mm×38mm×2m

3mm×20mm×300mm

*Alternative products for 3M 2900R tape
