1KV 10KV 20KV 35KV High voltage heat shrink bus-bar tube for short circuit
- 10000000 Meter / Meters per Month
- shenzhen
- Wenzhou Yika 7.2KV High Voltage Fuse 63 Amp
- China Silicone Thermal Pad Distributor for LED Lamp CPU GPU Cooling
- Wholesale Customized thermal conductive gap filler for GPU CPU Cooling
- Hot selling 7W thermal silicone Insulation Pad for gpu cpu cooling pad 0.5mmT Low thermal resistance
- 7W/mK Wholesale Customized Thermal Conductive Silicone Insulation Pad
- Thermal Silicone Insulation Pad For GPU CPU Cooling Pad Low Thermal Resistance
Product Details
Place of Origin: | Guangdong, China | Brand Name: | DICORE | Model Number: | HBBT |
Type: | Insulation Sleeving | Material: | PE | Application: | High Voltage |
Rated Voltage: | 1KV | Tensile Strength: | >=8MPa |
Product Description
1KV 10KV 20KV 35KV High voltage heat shrink bus-bar tube for short circuit
APPLICATION:
Heat Shrink Bus-bar Tubing Provides high resistance to tracking and arching and used to enhance the insulation properties of bus bar in switchgear and substation. The continuous length of supplied products makes it to be used more conveniently and economically.Avoid short circuit fault caused by small animals such as mice, snakes and so on. Prevent bus bar from chemical corrosion effected by strong acid, alkali, salt, etc. Avoid accidental injure, for instance, that overhaul person enter electriferous clearance by mistakes. Be suit to the trend of smaller switch cabinets. Be applied in bus duct for insulation among buses.
COLORS: Red, Green, Yellow, Black(Other colors available on request.)
Model | HBBT |
Material | PE material |
Type | 1kv, 10kv, 20kv, 35kv |
Tubing diameter | 20mm to 250mm |
Standard color | Red, green, yellow and black |
Operating temperature range | -55°C to 125°C |
Shrink temp | 115°C |
Insulation and protect bus bar |
Property:
1KV
SIZE (mm) | As Supplied(mm) | After Recovery(mm) | Packing (m/roll) | |
I. D. | I. D. (max) | W. T. | ||
30 | 31.5±1.0 | 15.0 | 1.0±0.15 | 50 |
35 | 36.5±1.0 | 17.5 | 1.0±0.15 | 50 |
40 | 41.5±1.0 | 20.0 | 1.0±0.15 | 50 |
50 | ≥50 | 25.0 | 1.1±0.15 | 25 |
60 | ≥60 | 30.0 | 1.2±0.15 | 25 |
10kv, 20kv
SIZE (mm) | As Supplied(mm) | After Recovery(mm) | Packing (m/roll) | |
I. D. | I. D. (max) | W. T. | ||
15 | ≥15 | 6.0 | 2.5±0.20 | 25 |
20 | ≥20 | 8.0 | 2.5±0.20 | 25 |
25 | ≥25 | 10.0 | 2.5±0.20 | 25 |
30 | ≥30 | 12.0 | 2.5±0.20 | 25 |
40 | ≥40 | 16.0 | 2.8±0.30 | 25 |
50 | ≥50 | 20.0 | 2.8±0.30 | 25 |
65 | ≥65 | 26.0 | 2.8±0.30 | 25 |
75 | ≥75 | 30.0 | 2.8±0.30 | 25 |
85 | ≥85 | 34.0 | 2.8±0.30 | 25 |
100 | ≥100 | 40.0 | 2.8±0.30 | 25 |
120 | ≥120 | 48.0 | 2.8±0.30 | 25 |
150 | ≥150 | 60.0 | 2.8±0.30 | 25 |
180 | ≥180 | 72.0 | 2.8±0.30 | 25 |
210 | ≥210 | 84.0 | 2.8±0.30 | 20 |
230 | ≥230 | 92.0 | 2.8±0.30 | 20 |
250 | ≥250 | 100 | 2.8±0.30 | 20 |
300 | ≥300 | 120 | 2.8±0.30 | 15 |
35kv
1KV 10KV 20KV 35KV High voltage heat shrink bus-bar tube for short circuit
