waste paper baler machine
Specification
1.This waste paper baler machine is uses the hydraulic transmission,with two cylinder operate,durable and powerful.
2.It uses the button common control which may realize the many kinds of work way.the machine working pressure traveling schedule scope can be adjusted according to the material bale size.
3.Special feed opening and automatic output packageof equipment.The operation is simple.the feed opening install the interlocking device which will be safe and reliable.
4.Pressure force,packing size may design according to customers requirement.
Parameter
Model | JPA1070T40 | JPA1070T60 | JPA1075T80 | JPA1075T100 |
Hydraulic power | 40Ton | 60Ton | 80Ton | 100Ton |
bale size(L*W*H) | 1100*700*500-900 mm | 1100*700*500-900 mm | 1100*750*500-900 mm | 1100*750*500-900 mm |
Feed opening size(L*H) | 1100*500mm | 1100*500mm | 1100*500mm | 1100*500mm |
Chamber Size(L*W*H) | 1100*700*1450 mm | 1100*700*1450 mm | 1100*750*1500 mm | 1100*750*1500 mm |
Capability | 6-12bales/hour | 5-8bales/hour | 4-6bales/hour | 4-6bales/hour |
Voltage(can be customized) | 200-480V/3Phase | 200-480V/3 Phase | 200-480V/3Phase | 200-480V/3Phase |
Power | 5.5KW/7.5HP | 7.5KW/10HP | 11KW/15HP | 15KW/20HP |
Machine size(L*W*H) | 1600*1100*3150mm | 1600*1100*3200mm | 1750*1200*3250mm | 1750*1200*3250mm |
Weight | 1800Kg | 2200Kg | 2600Kg | 3200Kg |
Machine parts
NAME | BRAND |
HYDRAULIC TECHNIQUE | REXROTH (Germany TECHNIQUE) |
HYDRAULIC ELEMENTS | YUTIEN,HYDOR (TAIWAN Brand) |
SEALING PARTS | HALLET(UK brand) |
ELECTICAL ELEMENTS | DELIXI(Europe brand ) |
OIL PIPE | ZMTE(Europe brand) |
MOTOR | JIABAO (Brand-specific Customized hydraulic motor, without junction axis ,lower noise, no maintenance and energy saving, safe and reliable |
PUMP | JINGGONG( Taiwan investment) above 50T DAZONG(Germany investment)below 40T |
Reasons for Choosing JEWEL Baler
JEWEL is a leader in providing customers with high quality baling solutions. We understand the baling industry, and we build extremely robust machines designed to handle your baling needs. What follows are what we feel are some solid reasons to choose JEWEL baler the next time you need a baler. | |
1 | JEWEL balers are CE certified, which assures operator’s safety |
2 | JEWEL baler are ISO9001:2008 certified, which guarantee the product quality |
3 | We utilize third-party inspections such as TUV,SGS and keep the reports for your perusal |
4 | JEWEL balers uses Bao steel (steel of the highest quality) to manufacture our balers |
5 | JEWEL balers also uses top quality hydraulics and electrical components from manufacturers you know |
6 | We travel to select clients to provide training, support, installation, and maintenance |
7 | We’re accessible, and will reply to any inquiry within 24 hours |
8 | WE provide first-class after sale service, any problem will be solved when happened |
9 | We do NOT skimp on packaging. Your baler is packaged to easily withstand the rigors of an overseas trip |
10 | We not only say the above – we’ll prove it |
machine appearance
our certification:
our factory:
