Help CenterMetal Hose Connector
Related Products
Model No. : SWCPU-R-MC065
Key words:
Universal metal hose joints
Universal metal hose connectors
Metal hose connectors
Universal adaptors
Detailed description:
Connector Type |
Name |
Applicable Common Diameter |
Code |
Remark |
|
Thread Connector Type |
Metric Thread |
Plane Connector Live Covering Nut |
DN6-DN50 |
TL1 |
Gasket Seal |
Sphere Connector Live Covering Nut |
DN6-DN50 |
TL2 |
Metal Wire Seal High Temperature Resistance |
||
Internal Awl Connector Live Covering Nut |
DN6-DN50 |
TL3 |
Metal Wire Seal High Temperature Resistance |
||
External Awl Threads Internal Connector |
DN6-DN50 |
TL4 |
Metal Wire Seal High Temperature Resistance |
||
|
55° |
Live Covering Nut Awl Hose Thread |
DN6-DN50 |
TL5 |
Everlasting High Temperature Resistance and Convenient to Allocation |
Awl Hose Outer Thread |
DN6-DN50 |
TL6 |
Everlasting High Temperature Resistance and Convenient to Allocation |
||
Awl Hose Inner Thread |
DN6-DN50 |
TL7 |
Everlasting High Temperature Resistance and Convenient to Allocation |
||
With Living Covering Nut Awl Hose Inner Thread |
DN6-DN50 |
TL8 |
Everlasting High Temperature Resistance and Convenient to Allocation |
||
Living Connector |
DN6-DN50 |
TL9 |
Everlasting High Temperature Resistance and Convenient to Allocation |
||
Steel Pipe Welding Type |
DN6-DN400 |
TH |
Everlasting Joint |
||
Flange Type |
ixed Flange |
DN20-DN400 |
TF1 |
Applicable to all temperature pressure |
|
Living Covering Flange |
DN20-DN400 |
TF2 |
Applicable to all temperature pressure |
||
Fixed Type |
DN20-DN400 |
TF3 |
Applicable to all temperature pressure |
||
Connecting Type |
Claw Type |
DN32-DN150 |
TK1 |
Applicable in frequency unpacking situations |
|
Pull-rod Type |
DN15-DN100 |
TK2 |
Applicable in frequency unpacking situations. |
||
Pull-rod Type |
DN15-DN100 |
TK3 |
Applicable in frequency unpacking situations. |
||
Open-close Type |
DN15-DN100 |
TK4 |
Applicable in frequency unpacking situations. |
||
Specification: Standard or according to customer’s requirements
Packing: Fibrage belt wrapping or according to customer’s requirement
Remark: We can produce products of Chinese standard, ANSI, DIN, JIS or be Non-standard
