Specifications
1.PLC,touch screen and weigning tool2.Servo motor driving system
3.storage of set paramter formula
4.sustainless 304 or 316
1.general description
This machine is an econimical and widly-purpose dry powder auger filling machine.there are three main parts:an auger metering head, pheumatic positioning device and the chain plate conveyer. It fits for low-fludity material and fludical substance,like milk powder,protein powder and pharmaceutical granular, condiment, solide drink , white sugar and carbon powder etc. It can also equip with other eqiupment, for example,capping sealing machine, labelling machine and unscrambling capping machine.
2.suitable samples
3.main features
1)stainless steel of 304 with quick disconnecting hopper
2)servo motor driving screw
3)PLC,screen touch and weigning module control
4) with fixed setting parameter in touch screen
5)with different screw model for different material
6)with adjustable handwheel
4.main technical datas
Model |
TP-PF-A21 |
TP-PF-A22 |
Control system |
PLC & Touch Screen |
PLC & Touch Screen |
Hopper |
Quick disconnecting hopper 35L |
Quick disconnecting hopper 45L |
Packing Weight |
1 - 500g |
10-5000g |
Weight Feedback |
By off-line scale (in picture) |
Online weight feedback |
Packing Accuracy |
≤ 100g, ≤±2%; 100 – 500g, ≤±1% |
≤ 100g, ≤±2%; 100 – 500g, ≤±1% |
Filling Speed |
15-40bottles per min |
15-40 times per min |
Power Supply |
3P AC208-415V 50/60Hz |
3P AC208-415V 50/60Hz |
Total Power |
1.2 KW |
1.6 KW |
Total Weight |
160kg |
300kg |
Overall Dimensions |
1500×760×18500mm |
2000×970×2030mm |
