GW-P4/S Multicolor Ball Pad Printing Machine With Shuttle System

Application:

This pnuematic four color tampon  printer is for bigger size workpiece,automatic color registration.But four times printing can complete a printing cycle,so low efficiency and easy operation, just needs one clamp,fitting for the products which is difficult in making plate and clamp,such as:electrical appliances,cups,stationary,barrel,gifts and so on

Function:

1.Professional manufacturing experience,the produce are update and improve constantly,quality is excellence

2.Printing speed and environmental quiet is the first-class in the same line,and other design performance are in a peor-leading position

3.Automatic computer control,flexible and reliable procedure,Adopts Japanese SMC pneumatic and electronic units,and also use harden bearings and defend from famous factory

4.Unique advantage,the head of machine can be adjusted and convenient to replace ink,pads,steel plate and parts,ink tray and printing size.Special design ink cuo and ink tray can use each other.at the same time,the ink up independent base can be adjusted X.Y direction,easy to do color registration,improve produce efficiency

5.All the machine is with security plate and cut emergency power system,meet international safety standard

Technical parameter:

Steel plate size:100*150mm

Printng speed:600PCS/HR

Power:220V /110V  50/60MHZ  30W

Air pressure:5-7BAR

Max.printing area:60*120MM

printing station:1PCS

Color:four color
