Printing Round/Oval container cylindrical screen printing machine GW-5A

Printing Round/Oval container cylindrical screen printing machine GW-5A

Product production:

1. All function is controlled by Mico-computer,high automatic and easy operation
2.4-digit automatic counter built-in
3.Having the function of printing cylindric or taper object
4.Both printing stroke and speed are adjustable that meets different printing requirement
5.Worktable adjustable on up/down,left/right and plane angle,easy and fast adjustment to
achieve high printing precision
6.Pneumatic printing controlled and equipped woth pressure adjustment system
7.The machine is controlled by mico-computer which is stability and reliability
8.Clear bright blue display,can display work estate of the machine at any moment
9.High-quality AUTONICS sensor and perfect fault alarm system
10.Convenient food switch,easy operation and maintained convenience
11.Light and steady aluminum alloy parts and import of enduring bearings and axle sleeves
12.International famous pneumatic units such us SMC,FESTO and so on
13.Independently printing and ink covering speed control.

Technical parameter:

 1.Action model option: fully automatic | semi-automatic | manual
2.Start-up method:panel | foot switches
3.vertical driving style: pneumatic
4.transeversa driving style:electric
5.vertical stroke: 100MM
6.max.printing area:1000MM (the length of circumference and cambered surface)*300MM (width)
7.printing diameter scope: 5--450MM
If you want to print the whole circle, the max printing diameter is 320MM
8.max length of products: 700MM
9.Max.printing speed:360pcs/Hr
10.Power:220V 50Hz
11.Out dimention:1650×1600×1450mm
12. weight:280kg

Actual printing machine pictures:

Printing sample:
