YOKOHAMA FENDER
In order to save client's cost,we can Deflated transport .(As client's need.)
1. Design Service Life?
Use as our advice it will be more than 15 years.
2. Warranty Period?
It is 3 years.
3. Do u obtain ISO9001, CCS and other certification?
Yes,We have CCC,CCS,SGS,BV,ISO9001,ISO17357-2002,GB/T21482-2008 certification ect.
4. Marine fender size?
Support Custom-made.
1. Value for Money, you will get the best price.
2. Unrivalled Expertise, we promise trustworthy product quality and service.
3. Good product lifespan and quality warranty.
4. Environment friendly and anti-collision.
! .XINCHENG has passed ISO9001:2000,SGS,China's top ten enterprises and top ten famous brands.
! .Production and test based on ISO17357-2002 AND gb/t21482-2008.
! .Customer's satisfaction is our duty.LR,CCS and other certificates are available to show you against your requirements.
♦—— Fiber layers:
♦—— Our equipment :
Yokohama Fender is the advanced anti-collision device for marine application in the world today. It uses compressed airbag as medium to absorb the impact energy when ship-to-ship contact(STS). It uses compressed air as medium to absorb the impact energy when ship-to-berthing(STB).
Comparing with traditional bumper style rubber fender, it has the following advantages:
1. More energy absorption.
2.Less reverse impact on ships.
3.Less weight.
4.Easy installation.
5.Softer and economical. etc.
...............................................................................................................
♦—— The structure of Yokohama Fender :
1. The outer rubber
Outside on the ball of rubber layer, which is used to protect by skeleton material and lining rubber ball
fromexternal force damage or wear.
2. The inner plastic
On the ball inside the rubber layer, which is used to prevent gas leakage and stay on the ball pressure.
3. Cord fabric layer
Composed of hanging plastic cord fabric, the lacquer that bake frame materials
4. Volume line ring
Placed in by ball end (or both) of steel ring, for fixed end cord fabric layer
5. The end of the flange
On the ball at the ends of the metal parts, can be installed charging valve and relief valve.
♦—— The specification of Yokohama Fender :
size D×L(m) |
Initial pressure(Po) is 0.05MPa |
Initial pressure (Po) is 0.08MPa |
||||
|
Weight kg |
R(kN) |
GEA(KJ) |
Weight kg |
R(kN) |
GEA(KJ) |
|
0.5×1.0 |
25 |
64 |
6 |
25 |
83 |
8 |
0.6×1.0 |
32 |
74 |
8 |
32 |
96 |
11 |
0.7×1.5 |
50 |
137 |
17 |
50 |
178 |
24 |
1.0×1.5 |
80 |
182 |
32 |
80 |
235 |
44 |
1.0×2.0 |
100 |
257 |
45 |
125 |
335 |
63 |
1.2×2.0 |
120 |
297 |
63 |
165 |
386 |
86 |
1.35×2.5 |
165 |
427 |
102 |
226 |
554 |
140 |
1.5×3.0 |
315 |
597 |
153 |
370 |
751 |
211 |
1.7×3.0 |
405 |
639 |
191 |
436 |
830 |
263 |
2.0×3.5 |
590 |
875 |
308 |
632 |
1138 |
424 |
2.5×4.0 |
1050 |
1381 |
663 |
1110 |
1815 |
925 |
2.5×5.5 |
1333 |
2019 |
943 |
1410 |
2653 |
1317 |
3.0×5.0 |
1880 |
2104 |
1210 |
2155 |
2709 |
1571 |
3.0×6.0 |
2160 |
2583 |
1485 |
2470 |
3292 |
1888 |
3.3×4.5 |
2020 |
1884 |
1175 |
2300 |
2476 |
1640 |
3.3×6.0 |
2300 |
2783 |
1675 |
2600 |
3652 |
2338 |
3.3×6.5 |
2700 |
3015 |
1814 |
3080 |
3961 |
2532 |
|
Height: the height of rubber fendernon- coxcombing, Inaccuracy of weight: ±10% Inaccuracy of reaction force: ±10% | ||||||
NOTE: Other Size also can be made as client's need.
♦—— The photos of Yokohama Fender :
♦—— Pressure Test:
PACKING : 1 .Packed in Woven bags or containter . 2 .It also depends on our clients' need .
DELIVERY : Usually 7 days, it depends on order's quantity.
PAYMENT TERM: 1. TT( 30% deposit, the balance money before shipment)
2. L/C at sight
Qingdao XinCheng rubber product Co.,Ltd which founded in 1986. It's a science and technology-oriented manufacturer that engaged in marine supplies. Selling all kind of marine fenders and airbag. Our company's branch — XinCheng Airbag Factory is a professional airbag factory which make load bearing, floating, store up and anti-collision airbags with many usage. Also XinCheng is a professional airbag and marine fender leading enterprise in QingDao.
Our company own many professional machineries (internal mixer, rubber mixing machine, four roll rubber calender, vulcanizer and vulcanizing boiler with various specifications) . Qingdao XinCheng rubber company is the only one enterprise who own CCC, CCS, ISO90001:2008, SGS,BV and Lloyd's Register of Shipping.
WELCOME TO VISIT OUR FACTORY!
Our company always adhere to the principle of "quality first" and provides our customers with good products and services.
We are looking forward to build business with you. If you have any questions, please feel free to contact me.
