Auto Granule Packing Machine With Filling And Feeding Machine
| Descriptive Abstract |
1.TP-L300K is suitable to pack small granular or powder products, such as peanuts,tea seeds etc.Automatically pack these products into plastic pouch,PE/laminated film acceptable.
2.Good sealing performance,widely used in food factory, fabrication plant,grocery.
3. Measure with volume cups, with 1% error, the bag former and vertical/horizontal sealing finish bag forming.
4. The packing material is heat seal-able rolled packing film,the cost is lower.
| Technical Parameter |
Model | TP-L300K |
Packing Speed | 30-60 bag/min |
Measuring Range | 3-300 ML |
Bag Size | (L):30-180(mm);(W):30-140(mm) |
Power | 220V/380V;single-phase 1.5KW |
Machine Weight | About 320KG |
Outline Dimension | 900*700*1700mm |
| Optional Devices |
1. Nitrogen gas filling
2. Linking bag device
3. Hole punch device
4. Ribbon printer
5. Air compressor
| Detailed Features |
1.English/Chinese human-machine touch screen operation.Controlled by
PLC,and has merits of stable performance and convenience for operation.Can make Three-sides,four-sides and back sealing.
2.Automatically finish the procedures of bag making,measuring filling,sealing cutting,counting and printing series number.
3.Advanced touch screen computer control and stepping driving motor are adopted to control the bag length with stable performance,convenient adjustment and accurate detection.
4.Intelligent temperature controller and PID adjustment make sure the error rage of temperature within 1℃.
| Sample |
General Package: Iron sheet case /plywood case with plastic film wrapping inside
Special Package : According to customer's requirement.
By EMS/ DHL: small quantity order.
By sea: container load.
Shanghai Topspack Industries Co.,Ltd has nearly 10 years of cooking machinery research and development history,with a large and medium-sized equipment more than 200 sets,the existing cooker mechanical engineering and technical personnel more than 50 people.We have won a good evaluation of the domestic market in order to high quality products and perfect after sale service.
