2-way electric operated valve with manual override 3-6V,9-24V, 85-265v for reuse of rainwater system

2-way electric control valve with 3-6V,9-24V and manual overried function for reuse of rainwater system

Parameter
Actuator rotation:90 degree
Actuator Motor:Reversible synchronous motor
Actuator color:Various
Control wirng:2,3,5 wires/CR01 to CR06 Wiring
Control Way:on/off,open autimatically when power-off,3-wires control,5-wires for signal feedback
Enclosure:IP65
Medium temperature:0-100°C
Open/close time:15Q-3sec/15N-5sec/25S-7sec/60P-11sec
Output torque:15Q-1.5Nm/15N-2N.m/25S-2N.m/60P-6N.m
Power Consumption:<2W
Pipe Connection:GB/BSP/ANSI/NPT
Pressure:1.0Mpa/150psi/PN10
Product life: 100,000 times
Rotation direction: Double acting
Size: 1/4",1/2",3/4",1",1 1/4" ,8mm,10mm,15mm,20mm,25mm,32mm
Special function:Position indicator;quick open
signal feedback,manual override
fail safe(auto-return) function
Valve body Material: Stainless steel (304, 316), Brass(Hpb58-3/59,Ni plated Barss
Working Medium:Pure water,water,50% glycol,Oil,Air
Features:
1.All-metal reducing gear
2.Available for 3-6VDC,12VDC,24VDC,110V/120VAC 220/230VAC work volatge
3.Electrical limit and machinery limit design,accurate position,avoid gear with switch.
4.Excellent sealing performance what sealing class is IP65
5.Float ball structure,no leakage,especially suitable for heavy pollution conditions.
6.Good substitution for solenoid or pneumatic valve.
7.High flow capability, 3 times flow rate more than traditional zone valves
8.High protection class,can be worked in moist conditions.
9.Large output torque, which suitable for the pipe system with much scaling.
10.Long service life 80,000 to 100,000 circles
11.Low working current, only 50 to 150mA
12.Mini dimension suits for small equipment
13.Multi-angle assembling,easy to install.suitable for both vertical and horizontal installation
14.Multiple voltage and control mode, applicable to a variety of occasions.
15.Optional manual lever for convenient operation when power is off
16.Patent technology of scale prevention design which can postpone the scaling time.
17.Small volume, compact structure, small and exquisite outlooks, various assembling methods with manual control and switch indication.
18.Smart shape,perform reliably,brass gear,PPO parts,large output torque.
19.Smooth flow, no block up
20.Replacing solenoid valve, particularly when solenoid cannot work reliably
21.Tight close, no leakage
22.The power is cut off when the valve reaches the on/off position
23.The actuator cover adopts close structure which is resistive to humidity and ensures reliable operation for motor
24.This ensures long life service for the actuator
Material of main parts:
Actuator: heat-resistant ABS
Body: brass or stainless steel
Ball: brass or stainless steel
Sealing: PTFE, silicon rubber ball seat, EPDM and NBR stem seat, NBR o-rings
Stem: brass or stainless steel
Applications:
1.Air-warm valve.HVAC and fire-flight sprinkler service,Fan coil and,hot water cycle system
2.Environmental Protection and drain water system,Water treatment project .
3.IC card meters,heat energy meters and reuse of rainwater and reuse of grey water system
4.Irrigation equipment,drinking water equipment,solar water heaters,washing machines,water heaters,industrial humidifier.
5.Small equipment for automatic control,agricultural water conservation and water-saving irrigation system
6.Solar thermal,under-floor,rain water,irrigation,plumbing service,hot water heating and solar glycol loop,ideal for off-grid system.
7.Water,Irrigation system,cooling/heating system,Low voltage plumbing system
8.Water equipment,auto-control water system,industrial mini-auto equipment, Small equipment for automatic control
Main Market:
Asia,Europe and North America
Paper Carton:
Large case:48x40x28(CM)/50-100pcs/0.054Cubic Meter
middle case:27x24x19(CM)/20-50pcs/0.012Cubic Meter
small case:13x10x8.5(CM)/1-2pcs/0.011Cubic Meter
