Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag

Qingdao Xincheng Rubber Products Co., Ltd.
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag thumbnail-1
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag thumbnail-2
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag thumbnail-3
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag thumbnail-4
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag thumbnail-5
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag thumbnail-6
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag photo-1
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag photo-2
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag photo-3
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag photo-4
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag photo-5
Vessel Launching/landing/hoisting/building/salvage Rubber Marine Airbag photo-6
US$ 300 - 8,000 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
XINCHENG
Model Number:
XC AF025
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name XINCHENG
Model Number XC AF025
Part Other, marine airbag

  vessel launching/landing/hoisting/building/salvage rubber marine airbag



Specifications

1.Reliable quality assurance

2.Competitive price advantage

3.Easy installation

4.Professional technology




Product Description





Qingdao Xincheng Marine airbags is China's independent intellectual property rights of innovative

products, the products are mainly applied to ship fluctuation, weight lifting, handling, installation

of underwater buoyancy aid, etc. Marine airbags have been used  widely , product less limited by

space, no large mechanical equipment, it can shorten the working period and save much money.

Through years of development practice, the product becomes more safe and effective, green

environmental protection, flexible, etc.



Applications:



1. Shipwreck salvage.



2. Floating bridge and dock construction.



3. Rescue and remove of wrecked ship.



4. Can be used as pontoons for supporting docks and other floating structure.





Airbag Structure:





Specification Form of Airbag:





1> Diameter (D)  : From 0.8m to 2.5m.



2> Effective Length (EL) : From 6m to 25m.



3> Total Length (TL) : From 7m to 28m.



4> Other specification of ship launching airbags also available upon customer’s request



Besides,we can according to your ship information provide you the most suitable size, etc.





DIAMETER

WORKING PRESSURE

WORKING HIGHT

GUARANTEED BEARING CAPACITY PER UNIT LENGTH

KN/m

T/M

Lb/ft





D=1.2m

(D=3.94FT)





0.17Mpa

(24.66psi)

0.7m(2.296ft)

133.61

13.62

9154

0.6m(1.968ft)

160.30

16.34

10983

0.5m(1.640ft)

187.08

19.07

12818

0.4m(1.312ft)

213.76

21.79

14646

0.3m(0.984ft)

240.44

24.51

16474

0.2m(0.656ft)

267.22

27.24

18309







D=1.5m

(D=4.92ft)







0.13Mpa

(18.85psi)

0.9m(2.952ft)

122.63

12.50

8402

0.8m(2.624ft)

143.03

14.58

9800

0.7m(2.296ft)

163.43

16.66

11198

0.6m(1.968ft)

183.94

18.75

12602

0.5m(1.640ft)

204.34

20.83

14000

0.4m(1.312ft)

224.75

22.91

15398

0.3m(0.984ft)

245.15

24.99

16797





D=1.8m

(D=5.90ft)





0.11Mpa

(15.95psi)

1.1m(3.608ft)

120.96

12.33

8287

1.0m(3.280ft)

138.22

14.09

9470

0.9m(2.952ft)

155.59

15.86

10660

0.8m(2.624ft)

172.85

17.62

11843

0.7m(2.296ft)

190.22

19.39

13033

0.6m(1.968ft)

207.48

21.15

14216

0.5m(1.640ft)

224.75

22.91

15398

0.4m(1.312ft)

242.01

24.67

16581

0.3m(0.984ft)

259.38

26.44

17771

0.2m(o.656ft)

276.64

28.20

18954

 NOTE : THE ABOVE VALLUE IS FOR REFERENCE ONLY . IT IS SUBJECT TO CHANGE IN ACCORDANCE WITH ACTUAL AIRBAG SYSTEM DESIGN .

YOU CAN CHOOSE THE REQUIRED OF SHIPS AND BOATS OF ALL SIZES. WE WILL MEET YOUR PROJECTS/SUPPLIED UPON CLIENTS REQUEST .







Inflatable Accessories of Airbag:





Packaging & Shipping





Delivery Detail : Around 7 days after receipt of payment.





Company Information



Qingdao Xincheng Rubber Products Co., Ltd, which was founded in 1986, is a collection of

production,scientific research and design, product development, technical services for the

integration of enterprises, is the professional manufacturer of ship launching  airbag,  Pneumatic  rubber fender, marine rubber fender in China area.  Company as the leading  enterprise has  passed the certification of CCS , ISO9001:2008, SGS, LR etc.





We are looking forward to  build business with you. If you have any questions, please feel free to contact me.
