Desulfurizer Activated Carbon for Sulfur Removal

Specifications

1. Sulfur removal activated carbon catalyst:

It is by special production process, select active raw material, with scientific formula production. It has high H2S removal capacity. This is not impregnated odor control activated carbon. During transport, use process and waste disposal etc will not encounter serious security problem like other alkaline impregnated carbon. Its’ ignition point is greater than 450°C.

It is a high surface area microporous activated carbon, own developed pore structure, without impregnating means in process of H2S catalyzed, oxidation, all of its pore and specific surface can storage large of sulfur.

2. Activated carbon for sulfur removal characters and advantage:

(1). Own particularly high ability H2S remove, H2S adsorption amount: 0.1-0.3g/cc

(2). It has a long service life in carbon bed, seldom interrupt due to the adsorption, reducing the running cost.

(3). High ignition, greater than 450°C.

(4). No impregnating, it can be handled safety (no corrosion).

(5). After finishing used(ineffective), it won’t occur dangerous because of PH.

(6). Low pressure drop, low bed resistance.

(7). It has technical support and analysis, testing methods when used.

3. Activated carbon for sulfur removal application:

It can be successfully applied to impregnated carbon or other odor control industry, CO2 existent doesn’t affect H2S and acid gas processing capacity. 4mm particle size, can reduce gas pressure loss in adsorption device, because of high strength, it seldom get powder form during use.

4. Activated Carbon for sulfur removal mainly application industry:

(1). Odor control, sewage treatment plant;

(2). Smelting, pulp and paper-making factory;

(3). Acid gases, such as: HCL, SO;

(4). Volatile organic compounds.

Note: H2S penetration measured by ASTM D6646-01 method.

5. Regeneration: washing regeneration

6. Packing:

Activated carbon for sulfur removal (25kgs/bag, 500kgs/bag, 1000kgs/bag) is packed in two-layer bag with plastic bag for inner packaging, woven bag or PP bag for external packaging.

7. Product specification:
