Marine Rubber Airbags for Ship Launching With Fast Deliver

Name: Marine Rubber Airbags for Ship Launching With Fast Deliver
Brand: Xincheng
SKU: 117041091
Availability: InStock

Qingdao Xincheng Rubber Products Co., Ltd.

US$ 200 - 2,000 MOQ: 2 Pieces

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Xincheng

Model Number:

XC.No. RA20129

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Xincheng

Model Number XC.No. RA20129

Part Other, marine airbag

World widely used custom Marine Rubber Airbag made in china

Product Description

Application:

1. Shipwreck salvage.

2. Floating bridge and dock construction.

3. Rescue and remove of wrecked ship.

4. Can be used as pontoons for supporting docks and other floating structure.

Structure:

Specification:

1> Diameter (D) : From 0.8m to 2.5m.

2> Effective Length (EL) : From 6m to 25m.

3> Total Length (TL) : From 7m to 28m.

4> Other specification of ship launching airbags also available upon customer’s request

DIAMETER	WORKING PRESSURE	WORKING HIGHT	GUARANTEED BEARING CAPACITY PER UNIT LENGTH
DIAMETER	WORKING PRESSURE	WORKING HIGHT	KN/m	T/M	Lb/ft
D=1.2m (D=3.94FT)	0.17Mpa (24.66psi)	0.7m(2.296ft)	133.61	13.62	9154
		0.6m(1.968ft)	160.30	16.34	10983
		0.5m(1.640ft)	187.08	19.07	12818
		0.4m(1.312ft)	213.76	21.79	14646
		0.3m(0.984ft)	240.44	24.51	16474
		0.2m(0.656ft)	267.22	27.24	18309
D=1.5m (D=4.92ft)	0.13Mpa (18.85psi)	0.9m(2.952ft)	122.63	12.50	8402
		0.8m(2.624ft)	143.03	14.58	9800
		0.7m(2.296ft)	163.43	16.66	11198
		0.6m(1.968ft)	183.94	18.75	12602
		0.5m(1.640ft)	204.34	20.83	14000
		0.4m(1.312ft)	224.75	22.91	15398
		0.3m(0.984ft)	245.15	24.99	16797
D=1.8m (D=5.90ft)	0.11Mpa (15.95psi)	1.1m(3.608ft)	120.96	12.33	8287
		1.0m(3.280ft)	138.22	14.09	9470
		0.9m(2.952ft)	155.59	15.86	10660
		0.8m(2.624ft)	172.85	17.62	11843
		0.7m(2.296ft)	190.22	19.39	13033
		0.6m(1.968ft)	207.48	21.15	14216
		0.5m(1.640ft)	224.75	22.91	15398
		0.4m(1.312ft)	242.01	24.67	16581
		0.3m(0.984ft)	259.38	26.44	17771
		0.2m(o.656ft)	276.64	28.20	18954
		NOTE : THE ABOVE VALLUE IS FOR REFERENCE ONLY . IT IS SUBJECT TO CHANGE IN ACCORDANCE WITH ACTUAL AIRBAG SYSTEM DESIGN . YOU CAN CHOOSE THE REQUIRED OF SHIPS AND BOATS OF ALL SIZES. WE WILL MEET YOUR PROJECTS/SUPPLIED UPON CLIENTS REQUEST .
