QTZ63 4810 Tower crane price in Tower Cranes
- 2 Set / Sets per Month
- Tianjin
- T/T
- cheaper 18T Tower Crane zoomlion used tower Crane 18T 7527-12T Construction Site Crane Engineering Crane used
- cheaper 18T Tower Crane used tower Crane 18T 7527-12T Construction Site Crane Engineering Crane used
- new 18T Tower Crane tower Crane 18T 7527-12T Construction Site Crane Engineering Crane used
- used 18T Tower Crane tower Crane 18T 7527-12T Construction Site Crane Engineering Crane used
- new12T Tower Crane tower Crane 12T 7020-12T Construction Site Crane Engineering Crane used
- used 12T Tower Crane tower Crane 12T Construction Site Crane Engineering Crane used
Product Details
Condition: | New | Application: | Construction | Rated Loading Capacity: | 1.0t |
Rated Lifting Moment: | 1250KN.M | Max. Lifting Load: | 4 ton | Max. Lifting Height: | 180M |
Span: | 60/55M | Place of Origin: | Beijing, China | Brand Name: | Jiuhong |
Model Number: | QTZ(4810) | Certification: | CE,ISO,GOST,GB | Warranty: | 1 Year |
After-sales Service Provided: | Overseas service center available |
Product Description
Tower crane price in Tower Cranes
1.The performance parameters and technical indicator of the crane are at a leading level in China.
The Maximum working radius is 50m and the maximum hoisting height is 150m.
2.The outline of the crane is international fashion model and very perfect, enjoyed by the users.
3. The tower hoist has many working mode, it is used in different condition. Such as: outrigger stationary,
chassis stationary, anchored to the building and mobile, so that it is applied in different construction projects.
The hoisting height of the outrigger stationary or the chassis stationary is 52m.
The hoisting height of the crane anchored to the building reaches to 150m based on the outrigger stationary
or the chassis stationary, added the tower sections M and anchored devices.
The maximum hoisting height can reach to 220m if the users have special demands.
4. It has high working speed and good regulated speed performance.
The technique of the stepless speed regulated and frequency altering is used in the trolleying mechanism
and the slewing mechanism, so the crane works more smoothly and reliably.
5. The main electric components are used world-renowned products, which service life is 3~4 times
longer than China-made counterparts with less failure, simple maintenance and reliable working.
6.All equipped safety devices are mechanical or mechanical-electrical integrated products,
and adapt to all badly conditions to ensure the crane working reliably.
Model | QTZ4810 tower crane | ||
Max Working Radius (m) | t.m | 48 | |
hoisting height | m | 30/120 | |
Max lifting load | t | 4 | |
Max working scope | m | 3-48 | |
hoisting speed | M/min | 0.62 | |
slewing speed | a=2 | R/min | 60/29/8.2 |
a =4 | 30/15/4.1 | ||
luffing speed | M/min | 38/26 | |
total motor power | KW | 25.1 | |
counter weight | t | 8.1 | |
fundation weight | t | 66 | |
Max working wind pressure | Pa | 250 | |
working temperature | ℃ | -20~+40 | |
Voltage/frequency | V/Hz | ~380/50 |
1.Tower hoist with Weight limier, height limiter, radius limiter, slewing limiter, slewing brake, traction brake
and similar safety guards
2.Rope-break-proof device (carriage slip-proof) and axle-break-proof device are used on the carriage;
3. Rope pay-off system for hoisting mechanism;
4. Traction rope-tensioning system;
5. Large-radius hoisting jib suspended by double rigid tie rods, featuring good jib rigidity, light jib weight,
small jib cross-section, small wind resistance and nice-looking appearance and several jib lengths, it is satisfied different construction needs.
6. Out-hung operator cabin, featuring excellent field of view, spacious interior, it is satisfactory working environment to the operator.
7. Advanced inter-active control console, the operator handles the mechanisms easy and services simply.
Tower crane main parts
No.1 driver room
No.2 mast section
No.3 Motor
No.4 swing device
1.We can make tower crane according to your requirement for tower crane height.
2.We can spray different colors for you.
3.We have one-year warranty.
1. Can you give me the tower crane price?
The price is depended on the height and loading capacity.If you send us more details,we will give you good price.
2.The tower crane loading weight?
This model 4810 series can lifting 4T.
3.The arm loading capacity?
1 ton
4. how many years have been exported?
more 8 years.
5.Do you have certificate?
We have CE,EAC and others standard.
6.How do I contact you?
You can send inquiry to us,we will send email to you.
