Beijing Manufacturer CE Standard Automatic Tower Crane Drawing

Name: Beijing Manufacturer CE Standard Automatic Tower Crane Drawing
Brand: JIuhong
SKU: 117003451
Availability: InStock

Beijing Jiuhong Heavy Industry Machinery Co., Ltd.

US$ 25,000 - 55,000 MOQ: 1 Set

Key Specifications

Condition:

New, New

Application:

construction, Construction

Rated Loading Capacity:

Payment & Shipping

Payment Methods:

Port of Shipment:

4808 Tower Crane

Delivery Detail:

Delivery time depends on order quantity.

Application construction, Construction

Rated Loading Capacity 6t

Rated Lifting Moment 56, 630 KN.M

Max. Lifting Load 6t, 4t

Max. Lifting Height 141

Span 50m, 48

Place of Origin Beijing, China

Brand Name JIuhong

Model Number QTZ4808

Certification CE

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Construction Building Tower Crane

Main Technical Parameters

tower crane drawing

Model	QTZ tower crane qtz40 4808
Model	QTZ50A(4808)
Jib Length(m)	48
Free Height(m)	30
Max. Height (M)	135
Max. Load (T)	4
Tip Load (T)	0.8
Wall-attached Devices for Max Height (sets)	5
Main Material (mm)	160×12 (Angle Steel)
Mast Section Dimension (m)	1.5×1.5 ×2.5
Hoisting Speed (a=2) (m/min)	58/29/8
Mini. Stable Falling Speed (m/min)	4
Slewing Speed (r/min)	0-0.62
Radius-changing Speed (m/min)	40/20
Total Jacking-up Speed (m/min)	0.5
Total Motor Power (kw)	23
Power Supply	380V/50HZ
Weight of Indepent Structure(T)	26.8
Counterweight(T)	8.10
Base Form	beam
Container Needed	4x40 HQ
