Specifications
Concrete Placing Boom 12m1.expand the scope of concrete pouring
uce labor intensity
3.simple operation
Concrete Spreader
Concrete Spreader is an assistant device in the concrete conveying construction. It could spread concrete in a large area and make the spreading work more flexible. It could extend the construction scope, increase pumping efficiency, save labors and promote the construction process. Its structure is very simple, flexible and easy to operate.
Technical Parameter
Name |
12m oncrete spreader |
15m concrete spreader |
18m concrete spreader |
Most radii slalom shorter radius |
12m |
15m |
18m |
Cantilever tube rotation radius |
6m |
7.5m |
9m |
Support section height |
5m |
5m |
6m |
Highly effective cloth |
5m |
5m |
6m |
|
Supporting the largest span |
3.4mX3.4m |
3.4mX3.4m |
3.4mX3.4m |
Body weight (counterweight) |
1290kg |
1400kg |
1700kg |
Counterweight (User-owned ) |
1200kg |
1300kg |
1800kg |
Concrete spreader project :
