Lilliput 4.3" Dual Frequency Sonar Depth Finder
Dual frequency sonar,
32 kinds of dominant hues,
Intelligent refreshing design,
Scientific arithmetic to measure targets more precision;
Real-time windows to revert real wave,
Images and sounds alert modes,
Friendly windows setting.
Feature:
High sensitivity gain adjusting function, clear fish-ID detection;
Automatic measuring range & bottom recognition;
Manually measuring range, waveform displays continuously;
Pause screen charting, move the cursor to measure target location;
Multiple alarm modes: depth & voltage;
Intelligent refreshing design to make wave avoid of staggering and dislocation;
User friendly Windows setting, like Large ditits view, Selectable background colors etc.
Specifications:
Display Screen |
4.3" LED backlit, 480x272 pixels |
Sonar Color |
32 kinds of dominant hues |
Display Mode |
Sonar View / Sonar Zoom View / Double Sonar View |
Auto Mode |
Range and sensitiveness self-regulation |
Waveform Display |
Continuous waveform under any setting |
Sonar Filter |
1~20 grades to filter noise |
Water Surface Noise |
1~20 grades to adjust |
Disturb Control |
Auto control disturb signals |
Cursor Operation |
To measure depth of any points in the picture |
Windows Mode |
5 customized windows modes |
Real-time window |
Color intension, Waveform |
Depth Excursion |
±5 meters |
Alarm Mode |
Upper depth/Lower depth/Low battery alarm |
GPS |
Latitude and longitude, Time/Date, Speed (GPS info needed) |
Resolution Ratio |
0.022 meter |
Chart Speed |
1~10 |
Background Color |
White, Blue, Black |
Working Frequency |
50/200KHz |
Depth Range |
1~400M |
Output Power |
300W |
Safety Grade |
IP64 |
Protection Function |
over-voltage protection, over-current protection, opposite polarity protection |
DC Adapter |
DC 8.5V~40V |
Working Environment |
0℃~50℃, 95% relative humidity |
Storage Temperature |
-10℃~50℃ |
Size(LWD) |
185.6×154.7×61.9 mm |
Accessories:
