Refrigeration Thermostatic Cooling Bath Thermostat Constant Temperature Unit Thermostat Bath Water Bath FC-series

Refrigeration Thermostatic Cooling Bath Thermostat Constant Temperature Unit Thermostat Bath Water Bath FC-series thumbnail-1
Refrigeration Thermostatic Cooling Bath Thermostat Constant Temperature Unit Thermostat Bath Water Bath FC-series thumbnail-2
Refrigeration Thermostatic Cooling Bath Thermostat Constant Temperature Unit Thermostat Bath Water Bath FC-series photo-1
Refrigeration Thermostatic Cooling Bath Thermostat Constant Temperature Unit Thermostat Bath Water Bath FC-series photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
LNEYA
Model Number:
FC-series
Contact Supplier Request Quote Chat Now
Wuxi Guanya Refrigeration Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name LNEYA
Model Number FC-series
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Refrigeration thermostatic cooling bath thermostat constant temperature unit thermostat bath water bath FC-series







Description:
It is widely applied to the field of bioengineer, medicine, food, chemical industry, metallurgy and petroleum, offering ideal constant temperature Equipment for the research institute, high-education institute, quality Control department and lab of the factory.

Features:
1. With self-diagnosis function, freezer overload protection, high pressure switches, overload relays, thermal protection device and other security functions.
2. Use the French compressor Tecumseh, filter drier Danfoss, solenoid valve Emerson, expansion valve.
3. LED display, clear, easy to operate.
4. Succeed in making the temperature decrease successively.
5. The liquid container is made by stainless steel, the volume is very suitable.
6. Adopt the environmental refrigerant to meet environmental requirements without using fluorine.
7. Multi-safety protection, more reliable operation.
8. Use the pump stir up to make the temperature in the container uniformly.
9. The function of correcting the temperature.
10. Independent automatic overheat preventive device.





Technical Parameters:



Model

FC-1020

FC-2020

FC-1040

FC-2040

FC-1060

FC-2060

Temperature range

-20.00℃~200.00℃

-40.00℃~200.00℃

-60.00℃~200.00℃

Temperature accuracy

±0.03℃

Temperature resolution

0.01K

Volume of container

25*20*20

40*25*20

25*20*20

40*25*20

25*20*20

40*25*20

Tank volume

10L

20L

10L

20L

10L

20L

Way of temperature control

PID adaptive controller

Way of circulation

20L/min,1bar The default is internal recycle, it can be made with external recycle mode.

Input and display

7-inch color touch screen display

Data record

Temperature curve record, data export to excel format and USB output interface

Function of alarm

Over-temperature alarm, sensor alarm, independent automatic overheat preventive device and alarm for refrigerator abnormity.

Sensor

PT100

Heating power

1200W

2500W

1200W

2500W

1200W

2500W

Cooling

power

200℃

1200W

2500W

1200W

2500W

1200W

2500W

50℃

1200W

2500W

1200W

2500W

1200W

2500W

20℃

1200W

2500W

1200W

2500W

1200W

2500W

0℃

1200W

2500W

1200W

2500W

1200W

2500W

-10℃

600W

1250W

1200W

2000W

1200W

2500W

-25℃





720W

1200W

1200W

2500W

-35℃





380W

800W

960W

2000W

-55℃









400W

900W

Material

SUS304

Case material

SUS304

Circulation connection size

External cycle connection size M24*1.5

Compressor

Embraco

Dry filter

Danfoss

Expansion valve

Danfoss

Refrigerants

R404A

R404A R508B

Size

45*55*85

50*65*95

45*55*105

50*65*125

45*55*135

50*65*145

Power

220V 50HZ

2500W max

220V 50HZ

4000W max

220V 50HZ

2700W max

220V 50HZ

4300W max

220V 50HZ

3000W max

220V 50HZ

5000 Wmax

Weight

85kg

100kg

130kg

150kg

145kg

185kg
