Specifications
zeller ophthalmic perimeter/visual field screener ,this perimeter need an extra computer to connect to it and then to use.zeller ophthalmic perimeter/visual field screener ,this perimeter need an extra computer to connect to it and then to use.
Our visual field perimeter with CE and ISO13485 ,with the top quality and very nice operation system. You can use it very well .
Stimulus Type :LED Stimulus Intensity:≤10000asb
Stimulus Size :Goldmann III
Stimulator Screen :Hemisphercal bowl, radius 30cm integrated
Main functions
Test range: Yellow spot test (central 0-10°)
Central 0-30°test
Quadrant test
Peripheral test (60-90°)
Scotoma test
Custom test
Test method: Estimative test
Qualitative test
Auto threshold
Fast threshold
Full threshold
Eye position central cursor Eye position tracking & alarm
Print out: digital image, grey image, colorful image, angle image, standard image, comparison image, 3D image, statistic result, Bebie curve Document management
Technical Specification :
Stimulus surface: hemispherical (radius: 380mm)
Wavelength: 580nm-650nm
Stimulus intensity: 2.5-1000 (asb)
Background intensity: 4 (asb)
Stimulus step: total 27 steps 1
Central sign diameter: 2mm
Stimulus points: 144(0-60°), 72(0-30°), 72(60-90°), 61(0-10°)
Chin-rest moving range: vertical 70mm, horizontal 90mm
