Formwork Beam/H20 Timber Beam/H16

Name: Formwork Beam/H20 Timber Beam/H16
Brand: COMACCORD
SKU: 116924751
Availability: InStock

US$ 3 - 34 MOQ: 1 Meter

Key Specifications

Place of Origin:

China

Brand Name:

COMACCORD

Model Number:

LKI1411112

Comaccord (Xiamen) Building Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name COMACCORD

Model Number LKI1411112

Specifications

Flange: Spruce
Thickness of Web: 27mm(+/1mm)
Poplar Plywood web in WBP glue
Painting: Yellow Waterproof Paint

COMACCORD H20 TIMBER BEAM

H20 BEAM(I-BEAM)

Flange: Spruce
Thickness of Web: 27mm(+/1mm)
Poplar Plywood web in WBP glue
Painting: Yellow Waterproof Paint
Length: from 1m to 6m

Length longer than 6m can be special ordered.

Application: Formwork

Specifications
Item	Formwork H20 Timber Beam
Wing Material	Imported spruce solid wood, finger-jointed and glueing according to DIN 68140-1
Web Material	Multilayer poplar plywood
Head Protection	Injection molding plastic head
Glueing	Finger-jointed between wings and web pursuant to approval notice Z-9.1-146
Moisture Content	less than 12% at the time of delivery
Surface Protection	The complete beam is waterproofed using a water-repellent color glaze
Color	Yellow or as customer's request
Wing Size	80x40mm
Standard lengths	2.45 / 2.90 / 3.30 / 3.90 / 4.90 / 5.90 m (Max.length:6.00m)
Mechanical Specification	Modulus of elasticity : E 11,000 N/mm2
Mechanical Specification	Shear modulus : G 600 N/mm2
Packing	Pallet or in bulk
Application	Level formwork system, Vertical formwork system, Adjustable formwork system, Curve formwork system, Irregular formwork, etc.
