Medium Capacity Liquid Filling Machine From Zhangjiagang

Medium Capacity Liquid Filling Machine From Zhangjiagang photo-1
Medium Capacity Liquid Filling Machine From Zhangjiagang photo-2
Medium Capacity Liquid Filling Machine From Zhangjiagang photo-3
Medium Capacity Liquid Filling Machine From Zhangjiagang photo-4
US$ 30,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port for filling machine
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V/380V
Power 3KW
Place of Origin Jiangsu, China
Brand Name YuFeng
Model Number CGF18-18-6
Dimension(L*W*H) 2200X2100X2200MM
Weight 2500kg
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

Medium capacity liquid filling machine From Zhangjiagang

 Medium capacity liquid filling machine From Zhangjiagang





Product Description

 Medium capacity liquid filling machine From Zhangjiagang

Medium capacity liquid filling machine From Zhangjiagang

---Description

The filling machine integrates washing,filling and capping into one unit,can be used for different kinds of non gas drink production.The advanced micro -negative pressure filling technology is used in this machine .The filling is quick ,steady and accurate.The beverage feedback system is well designed ,the gas can be fed back separately,has no contact with beverage reduce the second timepollution and oxidation .



Medium capacity liquid filling machine From Zhangjiagang
 ---Technical Parameter


Model

CGF8-8-3

CGF12-12-6

CGF18-18-6

CGF24-24-8

CGF32-32-10

CGF40-40-10

CGF50-50-15

Washing No

8

16

18

24

32

40

50

Filling No

8

12

18

24

32

40

50

Capping No

3

6

6

8

10

10

12

Production capacity(500ml b/h)

2000

4000

7000-8000

10000-12000

12000-15000

15000-18000

20000-22000

Installed Capacity(kw)

3

3.5

4

4.8

7.6

8.3

9.6

Overall size

2250*1800*2400

2450*1800*2400

2650*1900*2400

2900*2100*2400

4100*2400*2400

4550*2650*2400

5450*3210*2400




Medium capacity liquid filling machine From Zhangjiagang
---Rinsing-filling-capping 3 in 1 machine

Medium capacity liquid filling machine From Zhangjiagang



Medium capacity liquid filling machine From Zhangjiagang

---Detailed filling part photoMedium capacity liquid filling machine From Zhangjiagang

Medium capacity liquid filling machine From Zhangjiagang
---Capping part for ref

Medium capacity liquid filling machine From Zhangjiagang



Medium capacity liquid filling machine From Zhangjiagang
---Our electric control box

Medium capacity liquid filling machine From Zhangjiagang

Bottled Mineral Water / Drinking Water Filling Machine

---Spare parts supplierMedium capacity liquid filling machine From Zhangjiagang

Company Information

 Medium capacity liquid filling machine From Zhangjiagang

Medium capacity liquid filling machine From Zhangjiagang     ZhangJiaGang City YuFeng Beverage Machinery Co.,Ltd. is located in the economy developed golden delta zone along Yangster River.To the west of ShangHai and the east of NanJing,domestic and overseas transportation is very convenient.

    We are a manufactorying enterprise specializing in producing beverage packing equipment and various water advenced technologyfrom hone and abroad.So we have win high reputation among our customers.

    At present we produce:productiong lines for mineral water,pure water,fruit juice,tea drink,milk drink and carbonated drink with capacity 1000-20000bottles per hour; production lines for vinegar,soysouceand wine 1000-20000bottles per hour;3-5 gallon barreled water with capacity 80-1200 barrels per hour and various water treatment plants.

    "Honsty,Sincerity and good faith"is our spirit while "High technology ,high quality and high level"is what we aim.We try our best to satisfy our customers with our good after sale service.We would like to welcome all our society to cooperate and develop together.



Our Services

Medium capacity liquid filling machine From Zhangjiagang

---After Sales Service

1. Find our products through http://yufengjx.en.china.cn/

2. One year warranty for the whole system

3. Free equipment installation and debugging

4. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

5. Every 3 years, we can help to overhaul the machine free (Labor)

6. We can provide internship service and help you train the operator and mechanic

7. Free production technology and process configuration

8. We can help you to design the production line, workshop and provide turn-key project
