25Mpa working pressure homogenizer for juice drink
High pressure homogenizer - Description
Pressure through an adjustable current-limiting gap process, the formation of loss of pressure expansion, explosion, shear, combined effect of high-speed collision, the particles and liquid droplets shatter into very small size, while creating an ideal solution or dispersion of emulsion. Product stability, consistency, mixed, and easy absorption, nutritional value, shelf life, flavor, color, security activities are realized in the homogeneous process.
Widely used in food, dairy, beverage, pharmaceutical, fine chemicals and bio-technology and other fields of production, scientific research and technological development
High pressure homogenizer - Application
Main function of homogenizer include: improve homogeneity and stability of products, increase the period of maintenance and reduce reaction time, so as to save the
mass of activator and color.
High pressure homogenizer - Material
1. Main Frame, power supply box : cast iron;
2. Outer covering: 1cr17ni2;
3. Parts touching liquid:
3.1. pump chamber and inner turnbuckle: SUS 316L
3.2. the parts except pump chamber and inner turnbuckle: 1cr17ni2 (for durability);
Homomengizer - Technical parameter
| Name | type |
L/H | Rated pressure Mpa |
MPa | Weight | Size (mm) | Power Kw |
YFJJ | 500-25 | 500 | 25 | 0~20 | 670 | 1000×750×1100 | 5.5 |
1000-25 | 1000 | 25 | 0~20 | 670 | 1000×750×1100 | 7.5 | |
1500-25 | 1500 | 25 | 0~20 | 720 | 1000×750×1100 | 11 | |
1000-30 | 1000 | 30 | 0~24 | 720 | 1000×750×1100 | 11 | |
2000-25 | 2000 | 25 | 0~20 | 1150 | 1000×750×1100 | 18.5 | |
2500-25 | 2500 | 25 | 0~20 | 1250 | 1000×750×1100 | 22 | |
3000-25 | 3000 | 25 | 0~20 | 1350 | 1000×750×1100 | 30 | |
4000-25 | 4000 | 25 | 0~20 | 1400 | 1000×750×1100 | 37 | |
5000-25 | 5000 | 25 | 0~20 | 2000 | 1000×750×1100 | 45 |
♣♣♣ WELOME TO VISIT YUFENG FACTORY ♣♣♣
