Help CenterPYL 4 Inch Stainless Steel Ball Valve Hydraulic Ball Valve
Related Products
-
Stainless Steel Ball Valve 3 Way Ball Valve Flanged Ball ValveUS$ 25.7 - 2,000MOQ: 1 Set -
Electric Ball Valve Cast Steel Ball Valve Handles Made in ChinaUS$ 25.7 - 2,000MOQ: 1 Set
-
PYL 3 Inch Stainless Steel Ball Valve Flanged Ball Valve Dn40US$ 25.7 - 2,000MOQ: 1 Set
-
Electric Ball Valve Flanged Ball Valve PYL Dn100 ValveUS$ 25.7 - 2,000MOQ: 1 Set
-
1/8 1/4 Inch Once Piece 3000 Psi High Pressure 316ss 2 Way Ball ValveUS$ 15 - 25MOQ: 10 Pieces
Our product of ball valves
The main type and material of our valve products
| The main products of our company include: |
| (1) GOST 12820-80 12821-80 flanges |
| (2)DIN 2573 PN6 DIN 2576 PN10 DIN2502 PN16 DIN2503 P25-40 DIN2566 PN16 ,DIN2631-2635 flanges |
| (3)ANSI B16.5,A105 150LB 300LB 600LB 900LB 1500LB 2500LB WNRN SORF BLRF THRF SWRF LJRF flanges |
| (4)JIS 5K 10K 16K 20K 30K flanges |
| (5)BS4504 code101 105 111 112 113 flanges |
| Materials |
| Q235,A105,SS304,SS304L,SS316,SS316L,12Mn,16Mn,34Mn |
The structure of the PYL 4 inch stainless steel ball valve hydraulic ball valve
The material of the PYL 4 inch stainless steel ball valve hydraulic ball valve
| Item | Part. Name | Material |
| 1 | Bonnet | PE |
| 2 | Extension pipe | st37 |
| 3 | Body | st37 |
| 4 | Flat washer | st37 |
| 5 | Butterfly Spring | 60Si2MnA |
| 6 | Ball seat | SS202 |
| 7 | O-ring | EPDM |
| 8 | Ball washer | PTFE+20%C |
| 9 | Ball | SS304 |
| 10 | Stem washer | PTFE+20%C |
| 11 | Stem sleeve | st37 |
| 12 | Stem | SS410 |
| 13 | Stem ring | PTFE+20%C |
| 14 | Stem O-ring | FPM |
| 15 | Sleeve | st37 |
| 16 | Positioning PIN | ASTM1035 |
| 17 | Handle | st37 |
| 18 | Washer | Q235A |
| 19 | Nut | Q235A |
| 20 | Handle cap | ABS |
The feature of PYL 4 inch stainless steel ball valve hydraulic ball valve
| Type | Nominal pressure(MPa) | Testing pressure | Suitable temperature(°C) | Suitable medium | |
| Strength (water) (MPa) | Enclose (Water) (MPa) | ||||
| Q41 /61 H-16C | 1.6 | 2.4 | 1.76 | -40~200℃ | Water,Vapour,Oil |
| Q41 /61 H-25C | 2.5 | 3.75 | 2.5 | ||
The measurement of the PYL 4 inch stainless steel ball valve hydraulic ball valve
The manufacturing of the PYL 4 inch stainless steel ball valve hydraulic ball valve
For the flange, generally we use the wooden box and wooden pallet with plastic film, for the PYL 4 inch stainless steel ball valve hydraulic ball valve, we can use those two type, and also we use the Woven bag. In addtion, we can change the shape of the packaging according to customer requirements.
Except the PYL 4 inch stainless steel ball valve hydraulic ball valve,we can also supply the DIN standard flanges, JIS standard flanges, GOST standard flange, and kinds of valves.
If you need the Non- standard products ,according to your drawings, we can produce the product, that you most satisfied.
In Hebei, the base of the processing and transformation of casting steel flang(Suicheng,Baoding), and one of the largest Chinese Manufacturers of casting steel Valve are our supply chain,at the first link to ensure the clients' requirements. The delivery time is 7 -30 days
Our main marketsare South American , Spain, Italy, Russia , Middle East, Southeast
OUR WORLD MARKETS
1. Can i get free samples?
A: Yes,we can provide you the free sample, but you need to bear their own delivery costs.
2. Can I request to change the form of packaging and transportation?
A:Yes,We can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
3. Can i request to advance the shipment?
A: It should be depends on whether there is sufficient inventory in our warehouse.
4.Can i have my own Logo on the product?
A: Yes, you can send us your drawing and we can make your logo, but you have to bear
their own the cost.
5.Can you produce the products according to my own drawings?
A:Yes,we can produce the products according to your drawings that will be most satisfy you.
If you have any questions or you are interested in our products,please don't hesitate to contact us!!!
