5 Ton Truck Crane 8 Tons Telescopic Boom Truck Mounted Crane

US$ 20,000 - 30,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Construction

Rated Loading Capacity:

10000 Kg

CLW Heavy Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai or any port in china

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Construction

Rated Loading Capacity 10000 Kg

Rated Lifting Moment 6.72T.M

Max. Lifting Load 10000kg

Max. Lifting Height 14m

Span 12m

Place of Origin Hubei, China

Brand Name CLW

Model Number CLWCRANE 011

Certification ISO CCC

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

Product Description

5 ton truck crane 8 tons telescopic boom truck mounted crane

paramater of crane truck

Item	unit			Parameter
Vehicle model				5 Tons Truck with crane (LHD)
Horse Power	ps			210
Overall dimension	Mm			1110025003750
Internal dimension	mm			75002294550
GVW	Kg			25000
Rated loading capacity				12000
Mass in working order				12805
Wheel base				5370+1300
F/R track base				190/1860/1860
Approach/departure angle				32/12,32/13
Exhaust/Hp	ml/ps			5900/210
Max speed	Km/h			85
Tire specification	10.00-20			Engine type						B210-33
Traction system	6*4			transmission						6-speed
Number of axles	3			Electric system						24v
Operation control system	Electrically hydraulic control			Allowable passengers in cab						3
Equipment	1.Crane can be selected 2.Hydraulic valve is universal in the world on the safe side; three point floating type to protect crossbeam of the truck; all hydraulic pressure and 360°turning; new H-shape type; high precise drawn tube;24°tie-in.
Crane(XCMG Brand)	Number of sections						3
	Max working radius						12m
	Max lifting height						14
	Max lifting weight						10000Kg
Working radius (m)	2.5	3.5	4.5		5.5	7.0		9.0			12
Loading weight(Kg)	10000	7000	5500		4000	3200		2300			1500
Turing scope	360°		Crane Weight						3800Kg
Hydraulic pressure	26mpa		Tank volume						160L
Engine	COMMUNIS ENGINE, diesel engine,B210-33 ,210hp
Production cycle	30 workdays
Shipment	By bulk ship
FOB SHANGHAI
