Three-Phase Inverter Computer 120Kva Ups 220V
US$ 0.9 - 0.99
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
CHADI
Model Number:
CDD
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan/Guangzhou/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Online Market China 1000Watt Mini Ups 5VUS$ 0.9 - 0.99MOQ: 1 Piece -
Ups For Elevators 100Kva UpsUS$ 0.9 - 0.99MOQ: 1 Piece
-
Uninterruptible Power Supply 2000 Watts 10Kw Ups 1000WUS$ 0.9 - 0.99MOQ: 1 Piece
-
China Online Selling 1Kw 3000 Watt UpsUS$ 0.9 - 0.99MOQ: 1 Piece
-
110V 220V Elevator Home Online Ups PriceUS$ 0.9 - 0.99MOQ: 1 Piece
Place of Origin
China
Brand Name
CHADI
Model Number
CDD
Phase
Three Phase
Protection
Other, IP20
Weight
250-2600KG
Output Voltage
3 phases 380V±1%
Type
On-line
Application
Security / Monitoring / Alarm
Specifications
120Kva Ups 220V- Generator compatible
- Maintenance bypass available
- Isolation transformer available
Three-Phase Inverter Computer 120Kva Ups 220V
Chadi CDD series are the double conversion on-line UPS of three-phase inputs and three-phase outputs, ranged capacity from 10KVA~500KVA. This serial UPS apply dual DSP (Digital Signal Processor) controlled technology, and the 6th generation IGBT and static switch with low loss and high power.
Main Feature:
•DSP full digitalized control
•comprehenvise pretection
•enviromental protection and energy-saving
•friendly computer-human interface
•Superior loading characteristics
•High power dynamic performance
•Auto re-start function
•3-phases control seperately
•Self-diagnose
•super wide input voltage range
•optional
•3-proof technique
| MODEL | 10K | 15K | 20K | 30K | 40K | 50K | 60K | 80K | 100K | 120K | 150K | 160K | 200K | 250K | 300K | 400K | 500K |
| Rated power | 8KW | 12KW | 16KW | 24KW | 24KW | 40KW | 48KW | 64KW | 80KW | 96KW | 120KW | 128KW | 160KW | 200KW | 240KW | 320KW | 400Kw |
| INPUT | |||||||||||||||||
| Rated voltage | 3 phases, 5 wired system 380V±25%(285V-475V) | ||||||||||||||||
| Frequency | 60/50 Hz (optional±10%) | ||||||||||||||||
| power factor | ≥0.9(12 pulses rectification ) | ||||||||||||||||
| OUTPUT | |||||||||||||||||
| Rated voltage | 3 phases 380V±1% | ||||||||||||||||
| Frequency | 50/60Hz±0.1% (inverted tense) | ||||||||||||||||
| Phase precision | 120±10 | ||||||||||||||||
| Degree of 3-phase imbalance |
<±1%(under balance load voltages);<±3%(under 50% imbalance voltages); <±5%(under 100% imbalance loads) |
||||||||||||||||
| Distortion factor | Pure since wave,linear loads ≤3%;non-linear loads≤5% | ||||||||||||||||
| Overload capacity | Over load 125% can last 10 minutes, over load 150% can last 20 seconds | ||||||||||||||||
| Wave crest coefficient | 3:1 | ||||||||||||||||
| BATTERY(EXTERNAL EXTRA) | |||||||||||||||||
| Rated voltage | 384VDC | ||||||||||||||||
| Battery type and number | 12Vdc x 32 nos. | ||||||||||||||||
| Battery Voltage | 12 Vdc | ||||||||||||||||
| Back up time | extra battery(Extra position battery(standby time is determined by battery capacity)) | ||||||||||||||||
| System | |||||||||||||||||
| Transfer time | AC←→battery 0 ms;AC←→bypass < 4 ms | ||||||||||||||||
| Ingress Protection | IP20 | ||||||||||||||||
| Conversion Efficiency | ≥90%(inverted and full loading);≥97%(ECO mode) | ||||||||||||||||
| noise | 55db(1 meter) | 58db(1 meter) | 63db(1 meter) | 66db(1 meter) | 70db(1 meter) | ||||||||||||
| ENVIRONMENT | |||||||||||||||||
| temperature | 0℃~45℃ | ||||||||||||||||
| Humidity | 0~93% RH,non-condensing | ||||||||||||||||
| altitude | <1500m | ||||||||||||||||
| Size | |||||||||||||||||
| W×D×H(mm) | 800×600×1500 | 800×600×1700 | 1000×1000×1800 | 1000×1200×1800 | 1400×1300×2000 | ||||||||||||
| Weight | |||||||||||||||||
| N. weight (kg) | 235 | 275 | 295 | 335 | 390 | 430 | 460 | 680 | 800 | 920 | 1020 | 1080 | 1350 | 1450 | 1800 | 2050 |
2500
|
* Product specifications are subject to change without further notice | |||||||||||||||||
