12V 24V 1-1600rpm 37mm micro DC gear motor for civilian application

Name: 12V 24V 1-1600rpm 37mm micro DC gear motor for civilian application
Brand: LUNYEE
Price: USD $6.6 - 10 / Unit

FOB Price

USD $6.6 - $10 / Unit

1 Unit(Min.Order)

Product Details

Place of Origin:	Sichuan, China	Brand Name:	LUNYEE	Model Number:	L-SGM37-D
Usage:	Boat, Car, Electric Bicycle, Fan, Home Appliance, Other, Boat, Car, Electric Bicycle, Fan, Home Appliance, Electronic lock safe,electric vale and actuator,equipment apparatus	Certification:	CCC, CE, ROHS, UL, Other, CCC, CE, ROHS, UL, ISO9001	Type:	Other, Gear Motor, Scooter 12V DC gear motor
Torque:	0.5-100kg.cm	Construction:	Permanent Magnet	Commutation:	Brush
Protect Feature:	Drip-proof	Speed(RPM):	1-1600rpm	Continuous Current(A):	≤1.0A
Output Power:	0.5-100W	Voltage(V):	6-24VDC	Efficiency:	IE 2

MODEL	VOLTAGE		NO LOAD		AT RATED LOAD			AT STALL		Gearbox
	VDC		NO LOAD		AT RATED LOAD			AT STALL		Length
			SPEED	CURRENT	SPEED	CURRENT	TORQUE	TORQUE	CURRENT	L
	WORKING	NOMINAL	rpm	A	rpm	A	kg.cm	kg.cm	A	mm
L-SGM37D-24600	12.0-28.0	24	600	≤0.2	492	≤1.0	2.4	12	≤4.0	24.5
L-SGM37D-24600	12.0-28.0	24	300	≤0.2	240	≤1.0	4.7	24	≤4.0	24.5
L-SGM37D-24600	12.0-28.0	24	200	≤0.2	160	≤1.0	7	36	≤4.0	24.5
L-SGM37D-24600	12.0-28.0	24	120	≤0.2	91	≤1.0	11	60	≤4.0	24.5
L-SGM37D-24600	12.0-28.0	24	86	≤0.2	64	≤1.0	15.5	84	≤4.0	24.5
L-SGM37D-24600	12.0-28.0	24	67	≤0.2	50	≤1.0	20	108	≤4.0	24.5
L-SGM37D-24600	12.0-28.0	24	50	≤0.2	37	≤1.0	25	144	≤4.0	29.1
L-SGM37D-24600	12.0-28.0	24	40	≤0.2	29	≤1.0	31	150*	≤4.0	29.1
L-SGM37D-24600	12.0-28.0	24	29	≤0.2	21	≤1.0	44	150*	≤4.0	29.1
L-SGM37D-24600	12.0-28.0	24	22	≤0.2	15	≤1.0	56	150*	≤4.0	29.1
L-SGM37D-24600	12.0-28.0	24	13	≤0.2	9	≤1.0	91	150*	≤4.0	29.1
L-SGM37D-24600	12.0-28.0	24	12	≤0.2	8.5	≤1.0	100*	150*	≤4.0	29.1
L-SGM37D-24600	12.0-28.0	24	9.5	≤0.2	6	≤1.0	100*	150*	≤4.0	29.1
L-SGM37D-24600	12.0-28.0	24	7	≤0.2	4.5	≤1.0	100*	150*	≤4.0	29.1
Note:
1. This list is just for reference, we cam make the DC motor with Different voltage (6V,12V, 24V), speed(from 1rpm-1600rpm), and also different Gear Ratio, so the Gear motor’s final output voltage, speed, torque can be customized.
2. We can match different DC motor with this gearbox.
3. Gearbox shaft dimension is adjustable.

24V micro DC gear motor

Parameters and shaft size can be Customized. Non-standard prodcts can be sent in 15-25days.
