CNC Linear Motion Guide

CNC Linear Motion Guide thumbnail-1
CNC Linear Motion Guide photo-1
US$ 1 - 1,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Guide Width or Diameter:
9mm
Guide Length:
Customized
Model Number:
LY9
Contact Supplier Request Quote Chat Now
Chengdu Lunyee Imp. & Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo Qingdao Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Guide Width or Diameter 9mm
Guide Length Customized
Model Number LY9
Place of Origin Sichuan, China
Brand Name Lunyee

Specifications

CNC linear motion guide
1.Diameter:9mm
2.High rigidity
3.Low noise
4.Interchangeable

LUNYEE-Ensure linear motion more smoothly!

CNC linear motion guide



 CNC linear motion guide



Features

•  Heavy load, high rigidity, low noise



CNC linear motion guide



•  High efficiency, Blocks interchangeable



CNC linear motion guide



Certificates



CNC linear motion guide

 CNC linear motion guide



CNC linear motion guide

MODEL NO. Assembly size(mm) Slide Block size(mm) Slide guide rail(mm) Fixed bolt size of slide guide rail(mm)
H H1 N W B B1 C L1 L M×L         WR HR D h d P E
LY7S 8 1.5 5 17 12 2.5 - 9.6 18.8 M2 × 2.5 7 5 4.2 2.6 2.5 15 5 M2 × 6
LY9S 10 2 5.5 20 15 2.5 - 11.9 22.2 M3 × 3 9 5.5 6 3.5 3.5 20 8.5 M3 × 8
LY12S 13 3 7.5 27 20 3 - 13 25.5 M3 × 3.5 12 7.5 6 4.5 3 25 12 M3 × 8
LY15S 16 4 8.5 32 25 3.5 - 17.7 32.1 M3 × 4 15 10 6 4.5 3.5 40 18 M3 × 12

CNC linear motion guide

  • linear guide rail width range: 3mm, 5mm, 7mm, 9mm, 12mm, 15mm, 20mm, 25mm, 30mm, 35mm, 45mm, 55mm, 65mm
  • linear guide rail length range: customized, cut as per your requirement

Application

  • CNC machine, Food processing machine,
  • Printing machine, Lawn Mower,
  • Packing machine, Textile machine,
  • Factory automation,Motion control,
  • Industry control, Industry automation
  • Industrial robot, Medical equipment

CNC linear motion guide



Our Packages





CNC linear motion guide



Welcome to contact us to get more detailed products specs.



CNC linear motion guide
