fully industrial automation PLC logic controller for automatic packaging machine
MU2V series PLC is a motion control programmable controller , 8 channel independent 200Khz high-speed input and output , 4 road differential input and output , to support a variety of motion control instruction and 2/3/4 axis linear interpolation and 2 axis circluar arc interpolation instructions ,to meet the needs of users for a vareity of motion control .
| MU series PLC technical Specification Sheet of plc controller for automatic packaging machine | ||||
| General Performance | MU2V | MU2H | MU1H | |
| Max logical I/O point | 512 | 512 | 256 | |
| Max number of special modules | 8 | 8 | 0 | |
| High-speed pulse output | 8*200Khz support 4 road differential output | 2*100Khz(transistor output type) | ||
| Single-phase counting channel | 8*200Khz support 4 road differential input | 2*50Hz ;4*10Khz | 2*50Khz ;4*10Khz | |
| Double-phase counting channel | 4*200Khz | 1*25Khz , 2*5Khz | 1*20Khz ,2*10Khz | |
| Counting frequency comblined | 800Khz | 100Khz | 80Khz | |
| Basic instruction execution time | 0.050 μs | 0.084μs | 0.084μs | |
| Time to a program's instructions | 0.6ms/1K step | 1ms/1K step | 1ms/1K step | |
| Real-time clock | Support at least 3years when power supply drop | |||
| Constant scanning way | Support | |||
| Digital filter function | 0.8, 1.6, 3.2, 6.4,12.8, 25.6, 51.2 ms to adjust | |||
| Directive types | Basic instruction | 31pcs | 31pcs | 31pcs |
| Step instruction | 2pcs | 2pcs | 2pcs | |
| Applied instruction | 264pcs | 234pcs | 174pcs | |
| Storage | User program | 32K step | 24K step | 12K step |
| element holder | user set | user set | 2K character | |
| Components to keep time | Keep battery back-up for 3 years | |||
| MU2V series outstanding feature of plc controller for automatic packaging machine |
| The rich movement and positioning control functions |
| 1. High-speed Counter |
| High speed input up to 8channels ,support single-phase single count ,single phase double counting ,duplex counting three ways ,Support 4times the frequency count ,single phase high speed counting support 8*200Khz channel ,bipolar high-speed counting support 4*200Khz channel ,support 4 road differential input . |
| 2.High-speed Pulse Output |
| Up to 8 independent high-speed pulse output(max200Khz),support pulse+direction ,positive-negative pulse ,AB phase pulse output type ,support 4 road differential output . |
| 3.Envelope Pulse Output |
| Control the servo or stepping motor to multistep ,constant speed and the process of slow down ,the max is up to 256 step , suitable for speed change frequent occasions |
| GPS |
| Support the origin regression (DZRN),relative position control(DDRVI),DDRVA ,to stop DDVIT and PLSV ,HPRC |
| High speed , high-capacity |
| 1.MU2V series PLC ,basic instruction processing speed 0.050/step ,Comprehensive instruction processing speed 0.6/step ,Can satisfy the PID temperature control to adjust ,data communication ,high-speed positioning and complex computation ,requirement etc |
| 2.MU2V series PLC program step capacity can be up to 32k |
| Support MU2H series all function |
| Support MU2H series all extension module |
| MU2V Main Module of plc controller for automatic packaging machine | ||||
| Model | Input | Output | Output type | Size(L*W*H) |
| MU2V-1616MT | 16 | 16 | Transistor | 158*90*83 |
| MU2V-1616MT-CAN | 16 | 16 | Transistor | |
| Support 8 road hig-speed pulse output | ||||
| MU2V-1616MT1*1 | 16 | 16 | Transistor | 158*90*83 |
| MU2V-1616MT1-CAN*1 | 16 | 16 | Transistor | 158*90*83 |
| Support 4 road high-speed pulse output | ||||
| MU2V-2828MT*2 | 28 | 28 | Transistor | 226*90*83 |
| MU2V-2828MT-CAN*2 | 28 | 28 | Transistor | 226*90*83 |
| Support 4differential input and 4road high speed differential output | ||||
Shipping
1. Fedex/DHL/UPS/TNT for samples, door to door;
2. By air or by sea for batch goods for FCL, airport/port receving;
3. Customers specifying freight forwarders for negotiable shipping nethods.
4. Delivery time: 3~7 days for samples, 5~25days for batch goods.
Payment Terms
1. Payment : T/T, Western Uion, MoneygRAM, Paypal( 30% deposits, 70% balance before delivery); Trade assurance from Alibaba with 10000 dollars
2. MOQ: 1 set;
3. Warranty: 18 months
Why Choose Us ?
1. More than 15 Years' Experiece in Drivers Manufacturing: the complete industry chain: the strong R&D team, the powerful supply capacity, the prefect system of freight of forwarding, and the frst-class pre-sale service in any problem in operating PLC and converter.
2. Customization Production: size, model, package can be per customers' request.
3. Realizablw Quality: professional design team, strict QC system and strong transportation cooperation.
4. First-class Pre and After Service: we ensure the well processing of the practice of our products for customers.
Our warranty
3months free replacement,
18 months free maintenance
Life-time technical support and maintenance service
Due to the quality problem, free replacement part will be offered.
Due to incorrect use, unauthorized repaire, fall etc, the maintenance cost will be charged.
Q1: Are your PLC controller for automatic packaging machine quality mature and stable ? And which are the industry has run successfully ?
Yes , of course , we have CE ,CCC and ISO90001 certification .
Mature applicable in printing , pharmaceutical ,auto manufacturing ,electronic power ,medical devices etc .
Q2:How many the maximum points can up of your PLC controller for automatic packaging machine?
The main module at least 14 points ,maximum 60 points can extend to 512 points .
Q3: How many voltage are of PLC controller for automatic packaging machine ?Whether the voltage can be customized according customers ?
The input voltage AC110V~AC240V ,DC24V .Or according to customer .
Q4: What is guarantee of your PLC controller for automatic packaging machine ?
All series PLC to provide 18months warranty and lifetime maintenance .
Q5:What information should provide ,if want to get a quotation?
You could tell us your requirements and usage or our models
Take action to tell us your requirement let us solve !!!To click "send" as below
