fiber optic patchcord
1.SM,MM,SImplex,Dumplex available
2.High return loss, Low insertion loss
3.Quick delivery time
| Characteristics | Unit | Value/Performance | Comments | |||||
| SM | MM | |||||||
| PC | APC | |||||||
| Basic | ||||||||
| Insertion Loss (IL) | dB | <0.3 | IEC 61300-3-4 | |||||
| Return Loss (RL) | dB | SPC>45 UPC>50 | >60 | >23 | IEC 61300-3-6 | |||
| Endurance | dB | <0.2 | IEC 61300-2-2, coupling and uncoupling 500 cycles, clean every 25 cycles | |||||
| Operating Temperature | °C | -20 ~ +70 | ||||||
| Storage Temperature | °C | -40 ~ +70 | ||||||
| Ferrule end-face geometry | ||||||||
| Radius of Curvature (R) | mm | 10-25 | 5-12 | NA | Telcordia GR326(4.4.5) | |||
| Apex Offset | um | <50 | NA | Telcordia GR325(4.4.5) | ||||
| Fiber Protrusion | nm | <50 | <100 | NA | Telcordia GR326(4.4.5) | |||
| Fiber Under Cut | nm | <125@ R=7-10 | <100 | NA | Telcordia GR326(4.4.5). For PC, Under Cut <-0.02R3+1.3R2-31R+325 when R=10-25mm | |||
| Mechanical | ||||||||
| Drop | dB | <0.2 | IEC 61300-2-12, 1.5m, 5 drops, no damage | |||||
| Vibration | dB | <0.2 | IEC 61300-2-1, 10-55Hz, 0.75mm amplitude, 0.5 hrs/axis | |||||
| Flex | dB | <0.2 | Telcordia GR326(4.4.3.2), 0.9kg, +90°, 100cycles, for 2mm or larger cable | |||||
| Twist | dB | <0.2 | Telcordia GR326(4.4.3.3), 1.35kg load, +2.5 turns, 10 cycles, for 2mm or larger cable | |||||
| Pull Proof | dB | <0.2 | Telcordia GR326(4.4.3.4), 3.4kg at 90°, 6.8kg at 0°, for 2mm or larger cable | |||||
| Static Bending | dB | <0.2 | IEC 794-1-2, 60mm diameter 10 turns | |||||
| Crushing | dB | <0.2 | IEC 794-1-2, 102kg for 2mm or larger cable, 10.2kg for 900m cable | |||||
| Environmental | ||||||||
| Salt mist | No sign of corrosion | IEC 61300-2-26, 5% NaC1, 30°C, 7 days | ||||||
| Cold | dB | <0.2 | IEC 61300-2-17, -20°C, 96 hrs | |||||
| Dry Heat | dB | <0.2 | IEC 61300-2-18, 70°C, 96 hrs | |||||
| Damp Heat | dB | <0.2 | IEC 61300-2-19, 40°C, 95%RH, 96 hrs | |||||
| Transmission | ||||||||
| Characteristics | Unit | G652 SM | G655 SM | Std. 50um | 62.5um | OM2 | OM3 | |
| Max. Attenuation | dB/km (nm) | 0.4/0.3 (1310/1550) | 0.3 (1550) | 2.8 (850) | 3.0 (850) | 2.8 (850) | 2.8 (850) | |
| Min. Bandwidth | MHz·km (nm) | - | - | 500/500 (850/130) | 200/200 (850/1300) | 750 (850) | 2000 (850) | |
| Dispersion Coefficient | ps/ nm2·km | <3.0 (1310nm) | 2.6-6.0 (1550nm) | - | - | - | - | |
| Features | Applications |
| 1. Push-pull latching mechanism | 1. Telecommunication |
| 2. Non-optical disconnect performance | 2. Computer networks |
| 3.High quality zirconia ferrules | 3. CATV networks |
| 4. Materials meet RoHS requirements | 4. Active device termination |
| 5. Riser, Plenum, or LSZH cables available | 5. Instrumentation |
Package Notice:
There are different packages for different fiber optic components or devices.
The usual package is Carton. For Fiber Optic Adapter,Fiber Optic Pigtail, Fiber Optic Patch Cord,Fiber Optic Attenuator,Fiber Optic Terminal Box, Fiber Optic Splice Closure.They have an inner package individually and then will be packed into an outer carton.For Fiber Optic Cable, It is Wooden Drum.
Lead Time & Shipment Practice:
We usually send goods via DHL / UPS / Fedex / EMS / ARAMEX and airway for small order.We would arrange it for you if you have special requirements on it. Generally speaking, goods can be sent in 3-8 working days (depends on your order) after received payment.
For bulk order,We will arrange shipment by Air or by Sea after agreement with our customers.
Terms of Payment?
Usually, we accept payment by 100% T/T in advance (Telegraphic Transfer), West Union, PayPal and International Credit Card (small amount of money).
After Services:
We concentrate on our customers’ satisfaction, we have the professional after-service department, to solve the problems our customers meet in using, to enhance your benefits.We concentrate on our customers’ satisfaction, we have the professional after-service department, to solve the problems our customers meet in using, to enhance your benefits.
Q: Can you supply OEM or Odm Service?
A: We can supply OEM/ODM service absolutely!
Q: May I get free sample?
A: Normally, our product need sample fee, But we will charge your sample fee as less as we can, even sometimes free sample available. However, you have to pay us the courier cost like: DHL.FEDEX.UPS.TNT...
Q: What kind of payment methods and price term?
A: EXW, CIF, CFR, FOB ..etc. We accept Paypal, West Union, T/T usually. But we also accept L/C or OA under special situation.
Q: Warranty?
A: Products against defects are found to be defective under normal use within 1 year will be repaired without charge. If assume defects can’t be repaired will be replaced without charge within 1 year.
