industrial automation remote control analog to digital plc module
MU2H series PLC is a small scale of analog to digital plc module to combin with computer technology , communication technology ,automatic control technology and the result of the latest development of electrinoic technology .
| MU series PLC technical Specification Sheet | ||||
|
General Performance |
MU2V | MU2H | MU1H | |
| Max logical I/O point | 512 | 512 | 256 | |
| Max number of special modules | 8 | 8 | 0 | |
| High-speed pulse output | 8*200Khz support 4 road differential output | 2*100Khz(transistor output type) | ||
| Single-phase counting channel | 8*200Khz support 4 road differential input | 2*50Hz ;4*10Khz | 2*50Khz ;4*10Khz | |
| Double-phase counting channel | 4*200Khz | 1*25Khz , 2*5Khz | 1*20Khz ,2*10Khz | |
| Counting frequency comblined | 800Khz | 100Khz | 80Khz | |
| Basic instruction execution time | 0.050 μs | 0.084μs | 0.084μs | |
| Time to a program's instructions | 0.6ms/1K step | 1ms/1K step | 1ms/1K step | |
| Real-time clock | Support at least 3years when power supply drop | |||
| Constant scanning way | Support | |||
| Digital filter function | 0.8, 1.6, 3.2, 6.4,12.8, 25.6, 51.2 ms to adjust | |||
| Directive types | Basic instruction | 31pcs | 31pcs | 31pcs |
| Step instruction | 2pcs | 2pcs | 2pcs | |
| Applied instruction | 264pcs | 234pcs | 174pcs | |
| Storage | User program | 32K step | 24K step | 12K step |
| element holder | user set | user set | 2K character | |
| Components to keep time | Keep battery back-up for 3 years | |||
| MU2H series outstanding feature of analog to digital plc module |
| High Stability and High Reliability |
| 1.Wide operating voltage range: rated operational voltage AC100~240V ,Allowable operating voltage range AC85~264V |
| 2.Board a strict anti-corrosion treatment to adapt in the adverser environments ,working temperature -℃~55℃ ,can withstand |
| 3.The user program permanent preservation ? |
| 4. Excellent anti-interference |
| 5.Isolation of 24V DC power supply output ,can be directly to the sensor ,HMI ,external and intermediate relay to provide power . |
| High Speed and High-capacity |
| 1.MU2H series PLC basic instructions for processing speed is 0.084 μs/step ,comprehensive instructions for processing speed is 1K set/ms ,to satisfy the PID temperature control to adjust ,data communication ,high speed positioning control and complex computing . |
| Reliable Security Program |
| 1. Multi-level password-protected ,all the main program and subroutines can be encrypted separately ,Program can be binding Specified serial number of PLC ,to effectively protect the user intellectual property rights . |
| Super System Extension |
| 1.Support all MU2H series I/O extension module and special function module |
| 2. Support all MU2H series communication expansion card |
| The rich movement and positioning control functions |
| High-speed counter |
| Support single-phase single count , single phase double counting ,duplex double counting three ways .Support 4tims the frequency count ,High speed counting frequency totalled is up to 100KHz ,single phase high speed counting support 50KHz *2 aisle + 10Khz *4 aisle ,bipolar high-speed counting support 25Khz*1 aisle +5Khz*2 aisle |
| High-speed pulse output |
| Main module( transistor type) to offer 2 road independent of the high-speed pulse output ( max 100Khz) ,Support pulse-train output (PTO) and PWM two type . |
| High-speed pulse output |
| Main module(transistor type) to offer 2 road independent of the high-speed pulse output ( max*100Khz) support pulse-train output (PTO) AND PWM two type . |
| Envelope pulse output |
| Control the servo or stepping motor to multistep speeding ,conostant speed and the process of slow down ,the max is up to 256 step , suitable for speed change frequent occasions |
| GPS |
| Support the origin regression(DZRN) relative posistion control (DDRM ) ,DDRVA to stop DDMT and PLSV ,HPRC |
| Temperature PID |
| Integrated temperature control PID instruction (TPID) ,support 32 road temperature control and self-tuning to make temperature control to be simple by TPID insturction guide |
| Multi-protocol |
| To provide free port ,Modbus ,MxLink to convenient for system integration |
| Real-time clock |
| The main module built-in clock facts , to offer calendar function and support leap year compensation |
| MU2H Main Module | ||||
| Model | Input | Output | Output type | Size(L*W*H) |
| MU2H-1616MR | 16 | 16 | Relay | 158*90*83 |
| MU2H-1616MT | 16 | 16 | Transistor | 158*90*83 |
| MU2H-1616MR-CAN | 16 | 16 | Relay | 158*90*83 |
| MU2H-1616MT-CAN | 16 | 16 | Transistor | 158*90*83 |
| MU2H-3232MR | 32 | 32 | Relay | 226*90*83 |
| MU2H-3232MT | 32 | 32 | Transistor | 226*90*83 |
| MU2H-3232MR-CAN | 32 | 32 | Relay | 226*90*83 |
| MU2H-3232MT-CAN | 32 | 32 | Transistor | 226*90*83 |
| I/O extension module | ||||
| Model | Input | Output | Output type | Size(L*W*H) |
| MU2H-0800ENN | 8 | - | - | 58*90*83 58*90*83 |
| MU2H-0808ERN | 8 | 8 | Relay | |
| MU2H-0808ENT | 8 | 8 | Transistor | |
| MU2H-1600ENN | 16 | - | - | |
| MU2H-0016ETN | - | 16 | Transistor | |
| MU2H-0016ERN | - | 16 | Relay | |
| MU2H-1616ER | 16 | 16 | Relay | 158*90*83 |
| MU2H-1616ET | 16 | 16 | Transistor | |
| MU2H-1616ERN | 16 | 16 | Relay | |
| MU2H-1616ETN | 16 | 16 | Transistor | |
| Special Function modules of analog to digital plc module | |||||
| Module | Input | Output | Size | ||
| Input point | Input type | Output point | Output type | 58*90*83 | |
| MU2H-2AD | 2 | Voltage,current | - | ||
| MU2H-4AD | 4 | Voltage,current | - | ||
| MU2H-2DA | - | 2 | Voltage,current | ||
| MU2H-4DA | - | 4 | Voltage,current | ||
| MU2H-2PT | 2 | Thermal resistance | - | ||
| MU2H-4PT | 4 | Thermal resistance | - | ||
| MU2H-2TC | 2 | Thermocouple | - | ||
| MU2H-4TC | 4 | Thermocouple | - | ||
| MU2H-8TC | 8 | Thermocouple | - | ||
| MU2H-2PG | - | 2 | Pulse output | ||
| MU2H-2HC | 2 | Pulse input | - | ||
| MU2H-4ADH | 4 | High precision voltage and current | - | ||
| MU2H-4WT | 4 | Load sensor | - | ||
| Expansion Cards | |
| MU2H-CAN-BD | Support CAN2.0A/B CAN2.0 hardware(isolated) support free oral agreement MXLink agreements . |
| MU2H-RS485-BD | Support hardware interface RS485 |
| MU2H-CAN-RS232-BD | Hardware support CAN2.0/CAN2.0B ,RS232 interface |
| MU2H-RS232-BD | Support RS232 interface hardware |
| MU2H-1PG-BD | 1 axial pulse output card( pulse+direction) |
| MU2H-ETH-BD | 10/100m adaptation :support for TCP/IP protocol: programming port protocol and ModBus TCP protocol(from a stand) |
Shipping
1. Fedex/DHL/UPS/TNT for samples, door to door;
2. By air or by sea for batch goods for FCL, airport/port receving;
3. Customers specifying freight forwarders for negotiable shipping nethods.
4. Delivery time: 3~7 days for samples, 5~25days for batch goods.
Payment Terms
1. Payment : T/T, Western Uion, MoneygRAM, Paypal( 30% deposits, 70% balance before delivery); Trade assurance from Alibaba with 10000 dollars
2. MOQ: 1 set;
3. Warranty: 18 months
Why Choose Us ?
1. More than 15 Years' Experiece in Drivers Manufacturing: the complete industry chain: the strong R&D team, the powerful supply capacity, the prefect system of freight of forwarding, and the frst-class pre-sale service in any problem in operating PLC and converter.
2. Customization Production: size, model, package can be per customers' request.
3. Realizablw Quality: professional design team, strict QC system and strong transportation cooperation.
4. First-class Pre and After Service: we ensure the well processing of the practice of our products for customers.
Our warranty
3months free replacement,
18 months free maintenance
Life-time technical support and maintenance service
Due to the quality problem, free replacement part will be offered.
Due to incorrect use, unauthorized repaire, fall etc, the maintenance cost will be charged.
Q1: Are your analog to digital plc module quality mature and stable ? And which are the industry has run successfully ?
Yes , of course , we have CE ,CCC and ISO90001 certification .
Mature applicable in printing , pharmaceutical ,auto manufacturing ,electronic power ,medical devices etc .
Q2:How many the maximum points can up of your analog to digital plc module ?
The main module at least 14 points ,maximum 60 points can extend to 512 points .
Q3: How many voltage are of analog to digital plc module?Whether the voltage can be customized according customers ?
The input voltage AC110V~AC240V ,DC24V .Or according to customer .
Q4: What is guarantee of your analog to digital plc module?
All series PLC to provide 18months warranty and lifetime maintenance .
