3003 Prepainted Aluminum Coil For Aluminum Roller Shutter
We provide a series of aluminum products,such as aluminum circle,aluminum sheet,aluminum coil,mirror aluminum plate,embossed aluminum plate,aluminum plate,color aluminum plate,etc .
1) PE coated aluminum coil is made via rolling painting and baking, it has various bright colors with small color differences. It is resistant against impact and easy to be machined. All properties meet or surpass the national standard. the product is widely used in indoor and shop front decoration, ceiling roof tile, wall panel, advertisement board, counter, household electric apparatus, and inner and outer decoration of cars and ships.
2) The main raw material of PVDF fluorine carbon coating is PVDF fluorine carbon resin-polyvinylidene fluoride fiber. By maximum electric performance of fluorine atom, a stable and high fluorine bond can be formed. In addition to, the unique equal symmetrical molecular structure, the product are given with outstanding weathering resistance, excellent ultraviolet radiation resistance, and highly endurable corrosion resistance. The outdoor product color and brightness can be maintained for over 20 years. Because of high weather and impact resistance and the high pliability, the product has excellent machining property, and the coated colored panel can be further treated for pattern pressing. This product can be provided in two types: traditional fluorine carbon and nanometer fluorine carbon.
Raw Material
Aluminum Grade: 3005,3105,3003
Temper:H16,H26,H18,etc.
Surface Coating: PE&PVDF
Specification
Thickness:0.2-3mm
Coil Width: <1650mm
Coating Thickness:18-30um.
ID:405/505mm
Coil Weight:0.15-3MT
Gloss:10-90%(EN ISO-2813:1994)
Color: solid, metallic, glossy,wood grain,marble stone,embossed, etc.
You can choose our color chart, or we adjust the special color as the samples you offer.
Product Feature
1) High gloss
2) High flexibility
3) Excellent impact resistance
4) Excellent weather-proof resistance
5) Anti-ultraviolet
6) High erosion resistance
7) Stable color and gloss
8)Good mechanical processing performance
Coating Characteristic Table
| Test Item | Coating | |||||||
| PVDF | PE | |||||||
| Double layers | Three layers | |||||||
| Coating Thickness | ≥24 | ≥30 | ≥18 | |||||
| Glossy Tolerance | While 60°gloosy value ≥80 unit,tolerance±10 unit | |||||||
| While 60°gloosy value ≥20-80 unit,tolerance±7 unit | ||||||||
| While 60°gloosy value <20 unit,tolerance±5 unit | ||||||||
| Pencil Hardness | ≥1H | ≥2H | ||||||
| Flexibility of coating | While ≤2T,coating no crack or peer off | |||||||
| Adhesive property | 0 or 1 grade | |||||||
| Impact resistance | coating no crack no peer off | |||||||
| Acid resistance | Surface immersed with 5% HCL(V/V) for 48H | Surface immersed with 2% HCL(V/V) | ||||||
| without change | for 24H without change | |||||||
| Solvent Resistance | Brushing 200 times with butanone no appearance | Brushing 100 times with butanone no | ||||||
| to bottom | appearance to bottom | |||||||
| Chromatism | The coating color is almost the same as confirmed by buyer and seller,the color difference tested by | |||||||
| colorimeter between single coating and sample is less than 1.2(ΔE≤1.2),same lot products color difference | ||||||||
| ΔE≤1.0 | ||||||||
| Salt Fog Resistance | Outside 2mm the line which is scratched,no corrosion | |||||||
| and coating peel off | ||||||||
| Moisture Resistance | Coating change is less than 1 grade after 1000 hours | |||||||
| humidity test | ||||||||
| Weather Resistance | After 2000 hours xenon lamp shining test(artificially | |||||||
| accelerating ageing test),no powder come into being, | ||||||||
| glossy retention rate(after and before test percent rate) | ||||||||
| ≥85%,color change degree at least reaching to 1 grade | ||||||||
| Note:The test is as per China National Standard and Nonferrous Metals Industry Standard for color coated aluminum coil and ACP. | ||||||||
