JOY M&E pumps' product line includes the world's most dependable reciprocating triplex plunger pumps. This design allows a cost-effective pump to achieve high-efficiency and low-pulsation. JOY pumps field-proven dependability, efficiency, durability and versatility give users the best using experience.With highly-efficient pumps and proven dependability, JOY M&E's products are utilized world-wide in thousands of applications.
A wide product range of plunger pumps are available: 3LPM to 1200LPM, 20bar to3000bar. Pumps are available in brass, nickel aluminum bronze, 316 stainless steel and duplex stainless steel.
We offer a range of belt-driven pumps from 3LPM to 500LPM. Belt-drive is a very popular option because of the flow flexibility given within pulley ratios. Using a belt-drive isolates the pump from the heat and vibration of the motor or engine driving the pump. The belt also isolates shock from an engine or motor on start up, which can put excess wear on the crankshaft and drive end components. Belt-drive pumps give the flexibility of changing pump flow by a simple pulley change.
Triplex plunger pump is suitable as pressure testing pump, cleaning pump,metering pump, process pump, dosing pump, hydro test pump, transfer pump, slurry pump, liquid carbon dioxide pump and so on.
Triplex plunger pump is widely used in the field of valves pressure test, cylinder pressure test, industrial cleaning.
Assembling type: Horizontal type, Fixed type, and Trolley wheel type.
Drive type: Electric motor, Gasoline engine, Diesel engine.
Transmission type: Belt type, Gear box type, Speed reduction type.
Pump body material: Alloy steel, Martensitic stainless steel, Austenitic stainless steel, 316 & 316L stainless steel.
Model |
Pressure scope(Mpa) |
Flow rate LPM |
Power kW |
3DSY20 |
4~50 |
25~2 |
2.2 |
3DSY35 |
2~50 |
65-6 |
5.5 |
3DSY40 |
2~70 |
153~5 |
7.5 |
3DSY40A |
2~70 |
153~8 |
11 |
3DSY40B |
2~150 |
153~5 |
15 |
3DSY40C |
2~150 |
153~6 |
18.5 |
3DSY60 |
2~150 |
250~7 |
22 |
3DSY60A |
2~150 |
250~10 |
30 |
3DSY75 |
2~150 |
250~13 |
37 |
3DSY75A |
2~150 |
250~15 |
45 |
3DSY80 |
2~120 |
360~23 |
55 |
3DSY80A |
2~100 |
360~40 |
75 |
3DSY80B |
2~100 |
360~45 |
90 |
3DSY80C |
2~100 |
360~55 |
110 |
3DSY120 |
4~120 |
720~12 |
120 |
3DSY150 |
6~150 |
1790~19 |
45~300 |
