Digital display hydraulic test pump is the special testing equipment we produced for high pressure testing use for various vessels or tubes.
The whole set equipment is mainly including electric test pump, digital display controller, time relay, pressure sensor, explosion-proof shell, and remote etc.
Two operation types for your choice: Manual and Automatic.
Manual operation condition: The pressure boosting and pressure relief process are all controlled by manual.
Automatic operation condition: The pressure boosting and pressure relief process are all controlled by remote from a certain distance away. The set pressure could be set to any pressure value within the max. rated pressure. The equipment would start pressure boosting by remote. When getting to the set pressure, the equipment will stop automatically and keep the set pressure for settled pressure-keeping time. After a moment of the settled time, the audible and visual alarm will alarm and the operator to start the pressure relief process by remote and finish the whole testing process.
Model |
Rated pressure Mpa |
Liquid flow capacity L/h |
Motor power |
Overall size |
Weight kg |
1500 |
150 |
6 |
2.2Kw |
920X600X1100 |
250 |
2000 |
200 |
6 |
2.2Kw |
920X600X1100 |
250 |
