Help CenterFlute Tube Punching Machine
Related Products
Specifications
Flute tube punching machine is used for the flaring and flanging of copper pipe wall and makes the pipe look like a fluteFlute tube punching machine
Application: This equipment is used for the flaring and flanging of copper pipe wall and makes the pipe look like a flute (T type hole).
It is mainly applied in the air conditioning tubing field.
Main technical parameters:
1 |
Min machining pipe diameter |
phi 16mm (copper) |
2 |
Max machining pipe diameter |
phi 100mm (copper) |
3 |
Machining mode |
Punching |
4 |
Min distance of adjacent holes |
16mm |
5 |
Clamp mode |
Hydraulic power |
6 |
Electric control mode |
PLC PLC of Two axis |
7 |
Operating mode |
Auto/manual/ jog |
8 |
Loading mode |
Hand |
9 |
Pressure of hydraulic system |
5 Mpa |
10 |
Max machining W.thickness |
1.5mm |
11 |
Machining efficiency |
5-7sec/each hole |
12 |
Feeding axis travel(servo control) |
1300mm |
13 |
Positioning accuracy of feeding axis |
±0.1 |
14 |
Feeding axis speed |
800mm/s |
15 |
Rotating angle(servo control) |
±180° |
16 |
Power supply |
3phase 380V 50HZ |
17 |
Power of hydraulic motor |
2.2KW |
18 |
Volume |
Length 2.3m* width 1m*Height 1.5m |
