Cash deposit machine for banks/banknote deposit machine/kiosk for banks
Quick Information
~Robust 3.5mm cold-rolled cabinet
~5-8mm safe box with pin lock
~Enough space for more components and functions
~Easy access service through front door
We can customize kinds of kiosk cabinet per request, SDK &DLL &Communicate Protocol is for Free
Basic Configuration | ||
|
Central PC (Customizable) |
Motherboard |
B75 / H61 / H81 |
| CPU | Dual core i3/i5/i7 | |
| RAM | DDRIII 4G / 8G | |
| HDD | 500G, 7200rpm, 3.5" S-ATA | |
| Inter face | USB2.0*10,COM*10, VGA*2,DVI*1,SATA2.0*4,LAN*2,Audio*1,MIC*1 | |
|
Monitor
|
Screen size | 15", 17", 19" . |
| Brightness | 250cd/m2 ~400cd/m2 | |
| Contrast | 800:1 | |
| Response time | 5ms | |
| Dot pitch | 0.264mm | |
| Best resolution | 1280x1024 | |
|
Touch Screen |
Screen size | 15", 17", 19" . |
| Touch type | SAW, Infrared, Capacitive | |
| Resolution | 4096x4096 | |
| Feature | High transparence, precision and durability | |
|
Kiosk Enclosure |
Material | Cold-rolled steel ST12 SPCC with 1.5mm~2.0mm thickness. |
| Surface finishing | Car painting technology. Steel cabinet sprayed metallic paint, Anti-rust, Anti-acid, Anti-dust. | |
| Color and Logo | Customizable | |
| Features | Easy service access through front or back door. |
|
| Accessories | Speakers | Stereo loudspeaker, 8Ω 10W |
| Fans | Internal ventilation system | |
| Power Supply | Input voltage | 100~240V/AC |
| Frequency | 50Hz to 60Hz | |
| Operation System | Windows 2000 / Windows XP / Windows 7 / Vista / Windows 8 / Linux | |
| Package | Safe packing with bubble foam, carton box or plywood case | |
| Safety | Anti-vandal safety; | |
| Electric safety: compliant with GB4943 Standard; | ||
| EMC(Electro Magnetic Compatibility): Compliant with GB9254 and GB/T17626 Standard | ||
| Monitoring system: Digital video security monitoring system (optional) | ||
|
Data safety: EPP is compliant with VISA Security Standard, PCI compliant (optional) ; Card reader is compliant with EMV Level1 Standard; | ||
All hardware and SDK are WOSA/XFS and ISO8583 compliant.
SDK are Free of Charge.
|
Select optional devices according to your needs
| ||
Printer |
Thermal Printer : Width 56mm /78mm /80mm /112mm /210mm; black mark sensor; full/half cutter |
|
|
Card reader
|
Magnetic Card: ISO7810 ID-1,7811 |
|
| RF ISO14443 Type A & B | ||
| Mifare | ||
| IC Card: ISO7816-2, T=0,T=1 CPU Card,SAM Card | ||
| Cash or coin modules | Cash acceptor | Acceptance:> 96%, capacity: 600notes, 900notes, 1000notes, 1200notes, 2200notes. |
| Cash dispenser | 1 to 6 cassettes | |
| Coin dispenser | Coin diameter: 18~28.5mm, thickness: 1.65~3.2mm; | |
| Cash recycler | Recycle 80 notes in mixed denominations; Recycle 1 to 4 denominations | |
| Keyboard |
EPP | 3DES Metal EPP : 16 keys, waterproof, dustproof, vandal proof IP65 |
| Other peripheral | Wifi /GPRS /Webcamera /UPS /3G Module | |
Kiosk Application
Public places: Bus, Sub Way, Airport, Gas Station, Book store, Exihibition Hall, Park,
Stadium, Museum, Convention Center, Ticket agency
Business Organization:Supermarket, large-scale shopping mall, chain shops,
star-rated hotels, restaurant, travel agency, Pharmacy
Financial Organization: Banks, negotiable securities, funds, insurance company, Pawnshop
Non-profit Organization: Telecommunications, post office, hospital, school
Entertainments: Movie theaters, fitness halls, country clubs, massage room, bars, cafe,
internet bar, beauty shop, golf course
Shipping
Sample 3-7 days to the World by air or DHL/Fedex etc express
bulk order to the world by sea or air upon the country
