Home > Manufacturing & Processing Machinery > Textile Machinery & Parts > Knitting Machine > High Speed Narrow Fabric Needle Loom (JX-NF8/27)

High Speed Narrow Fabric Needle Loom (JX-NF8/27)

Name: High Speed Narrow Fabric Needle Loom (JX-NF8/27)
Brand: Jinxin
SKU: 116753259

High Speed Narrow Fabric Needle Loom (JX-NF8/27) thumbnail-1

High Speed Narrow Fabric Needle Loom (JX-NF8/27) photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Jacquard

Place of Origin:

Zhejiang, China

Contact Supplier Request Quote Chat Now

Ruian City Fenghao Industry&Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Jacquard

Place of Origin Zhejiang, China

Brand Name Jinxin

Model Number JX-NF8/27

It is applicable to produce kind of elastic and unelastic tapes with kinds of pattern, characters, sign and so on. And the tapes are used as twist belts, underwear belts, and so on.

1)Main characters:

1.The open frame construction is a special design, it essures machine runs quietly under high speed and long
time.

2.The machine is produce precisely, highly-compatible with spare parts, easy adjust and repair.

3.Auto oil circulation system, auto oil feeding detection.

4.Double motor design, adapt to fast adjusted for the machine.

5.With "double hook single needle" and "double hook double needle" devices. It can be apply to produce breast
tape, shoulder tape, curtain tape and so on.

6.PC control design, motor start-stop, warp-stop, yarn-stop display. Output calculation, auto-return after stop.

2)Special Equipment:
N: Normal equipment
DR: Double-roller device
DH: Double hook single needle
DW: Double hook double needle
DP: Double picot forming warp
DPw; Double picot forming weft
DWT: Double hook double needle double tier

3) Technical Parameter:

Machine Model	8/27	6/42	4/66
No. Of Spaces	8	6	4
Max Reed Width	27mm	42mm	66mm
Shedding Motion	12-20	12-20	12-20
Pattern Chain Repeat	48	48	48
Motor Power	1.5H.P	1.5 H.P	1.5 H.P
Rotation Speed	1,300-1,500 rpm	1,300-1,500 rpm	1,200-1,300 rpm
Weft Density	2.9 -40.5cm	2.9 -40.5cm	2.9 -40.5cm
Special Equipment: DR/DH	DH	DH	N
