N Male to SMA Female RF Coaxial Adapter Connector
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DM, DM
Model Number:
N male to SMA female RF coaxial adapter connector
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SMA Male to SMB Female RF Adapter ConnectorNegotiableMOQ: 100 Pieces -
RF Antenna TV Coaxial Cable Female to F Female Jack Plug AdapterNegotiableMOQ: 100 Pieces
-
Nickel F Female to IEC Male Coaxial Connector AdapterUS$ 50,000 - 1,000,000MOQ: 100 Pieces
-
RF Adapter RCA Female to F Male Coaxial ConnectorNegotiableMOQ: 100 Pieces
-
RF Coaxial Coax Adapter SMA Male to UHF Female SO-239 SO239US$ 0.8 - 1.1MOQ: 100 Pieces
Place of Origin
Jiangsu, China
Brand Name
DM, DM
Model Number
N male to SMA female RF coaxial adapter connector
Type
Other, Adapter, N male to SMA female RF coaxial adapter connector
Application
Other, RF, RF
Gender
Other, male/female, female/male
N male to SMA female RF coaxial adapter connector
Series SMA are very popular thread coupling miniature coaxial connectors.Which have the excellent performances of high reliability,high mechanical strength,high durability,and optimum electrical properties, are widely used to connect RF coaxial cables for mobile communication equipments and electronic communication instruments
| Key Performance | ||||||
| Temperature range | -65~+165 | Insulation resistance | ≥5000MΩ | |||
| Characteristic impedance | 50Ω | Dielectric Withstanding voltage | 1500V | |||
| Frequency range | 0~11GHz | Contact resistance | Center conductor | ≤1mΩ | ||
| Outer conductor | ≤0.2mΩ | |||||
| VSWR | ≤1.30 | Durability | 500 Cycles | |||
| Material And Plating | ||||||
| Body | Brass , gold/nickel plated | |||||
| Male center contacts | Brass , gold plated | |||||
| Female center contacts | Beryllium copper or phosphor bronze , gold plated | |||||
| Insulators | PTFE | |||||
| Gaskets | Silicone rubber | |||||
| Crimp ferrules | Copper alloy , nickel plated | |||||
