DK-Mini350 2.5A~350Ap-p Oscilloscope Current Probe( Rogowski Coil)

DK-Mini350 2.5A~350Ap-p Oscilloscope Current Probe( Rogowski Coil) thumbnail-1
DK-Mini350 2.5A~350Ap-p Oscilloscope Current Probe( Rogowski Coil) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DKFLEX
Model Number:
DK-Mini350
Contact Supplier Request Quote Chat Now
Guangzhou Dekem Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
gz
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name DKFLEX
Model Number DK-Mini350

DK series(Specification)--Flexible current probe, used withoscilloscopes, recorders or data loggers

DK-Mini350 current probe( Rogowski Coil)



Please refer the datas to the matched model:



Flexible Current probe

   >> Coil circumference:120 to 1000mm(at your request)

   >> Coil cross section(max):3KV (depend on the coil size)

   >> Temperature range: -10°C-100  centigrade

   >> Cable length(from box to coil):2m

   >> Power supply: DC supply adaptor or 6-9v or 4 batteries

   >> Integrator box dimension: H=160mm,W=80mm,D=28mm

   >> Coil cross section(max):3mm,3.5mm,4mm or 8mm(with sleeve)

   >> Output socket:BNC(1MΩ,AC)

Model

Sensitivity

 mV/A

Peak-peak

Current(A)

Measurement from(A)

DC offset

  /mV

Peak di/dt

 kA/μs

Bandwidth

(3db)

Accuracy

DK-Mini070

100

70

0.5

±2

0.2

45Hz-4/8MHz

1%+2mV

DK-Mini140

50

140

1.0

±2

0.2

45Hz-4/8MHz

1%+2mV

DK-Mini350

20

350

2.5

±2

0.4

45Hz-4/8MHz

1%+2mV

DK-0700

10

700

5.0

±2

0.6

5Hz-6/10MHz

1%+2mV

DK-1400

5

1400

10

±2

0.6

5Hz-15MHz

1%+2mV

DK-3500

2

3500

25

±2

0.6

5Hz-15MHz

1%+2mV

DK-7000

1

7000

50

±2

0.8

5Hz-15MHz

1%+2mV

DK-14000

0.5

14000

100

±2

50

5Hz-15MHz

1%+2mV

DK-35000

0.2

35000

200

±2

50

5Hz-15MHz

1%+2mV

DK-70000

0.1

70000

200

±2

50

5Hz-15MHz

1%+2mV

DK-140000

0.05

140000

200

±2

50

5Hz-15MHz

1%+2mV

DK-350000

0.02

350000

1000

±2

50

5Hz-15MHz

1%+2mV





DK flexible current probes Circumference/Diameter of the coil option:





Diameter(mm)

2.5

3.5

3.5

5.5

5.5

8.0

8.0

8.0

Circumference(mm)

100

200

300

300

500

500

700

1000



 DK-Mini350 2.5A~350Ap-p oscilloscope current probe( Rogowski Coil)DK-Mini350 2.5A~350Ap-p oscilloscope current probe( Rogowski Coil)DK-Mini350 2.5A~350Ap-p oscilloscope current probe( Rogowski Coil)DK-Mini350 2.5A~350Ap-p oscilloscope current probe( Rogowski Coil)DK-Mini350 2.5A~350Ap-p oscilloscope current probe( Rogowski Coil)DK-Mini350 2.5A~350Ap-p oscilloscope current probe( Rogowski Coil)
