DK series(Specification)--Flexible current probe, used withoscilloscopes, recorders or data loggers
DK-Mini350 current probe( Rogowski Coil)
Please refer the datas to the matched model:
Type |
Sensitivity mV/A |
Peak-Peak Current(A) |
Min. Current ( A) |
Noise (mV Pk-Pk) |
Bandwidth (3db) |
Accuracy |
DK-Mini070 |
100 |
70 |
0.5 |
5 |
45Hz-4/8MHz |
1%+2mV |
DK-Mini140 |
50 |
140 |
1.0 |
5 |
45Hz-4/8MHz |
1%+2mV |
DK-Mini350 |
20 |
350 |
2.5 |
5 |
45Hz-4/8MHz |
1%+2mV |
DK-0700 |
10 |
700 |
5.0 |
5 |
5Hz-6/10MHz |
1%+2mV |
DK-1400 |
5 |
1400 |
10 |
5 |
5Hz-15MHz |
1%+2mV |
DK-3500 |
2 |
3500 |
25 |
5 |
5Hz-15MHz |
1%+2mV |
DK-7000 |
1 |
7000 |
50 |
5 |
5Hz-15MHz |
1%+2mV |
DK-14000 |
0.5 |
14000 |
100 |
5 |
5Hz-15MHz |
1%+2mV |
DK-35000 |
0.2 |
35000 |
200 |
5 |
5Hz-15MHz |
1%+2mV |
DK-70000 |
0.1 |
70000 |
200 |
5 |
5Hz-15MHz |
1%+2mV |
DK-140000 |
0.05 |
140000 |
200 |
5 |
5Hz-15MHz |
1%+2mV |
DK-350000 |
0.02 |
350000 |
1000 |
5 |
5Hz-15MHz |
1%+2mV |
Coil circumference:100,200 or 1000mm
Coil cross section(max):1Kv
Temperature range: -10°C-100°C
Cable length(from box to coil):2m or 4m
Power supply: DC supply adaptor or 6-9v or 4 batteries
Integrator box dimension: H=160mm,W=80mm,D=28mm
Coil cross section(max):2mm-14mm(with sleeve)
Output socket:BNC
DK flexible current probes Circumference/Diameter of the coil option:
Diameter(mm) |
2.5 |
3.5 |
3.5 |
5.5 |
5.5 |
8.0 |
8.0 |
8.0 |
Circumference(mm) |
100 |
200 |
300 |
300 |
500 |
500 |
700 |
1000 |
