PT-2770(AC/DC,20KHz,10A~1500Ap-p)hall Effect Current Clamp Probe

Product Introduction

Product Name:

PT-2770(20KHz,2A-1500Ap-p)current clamp

Short Description:

PT-2770 DC-20KHZ AC/DC current probe
10A-150Ap-p 150A-1500Ap-p

Model Number

PT-2770

Range

50mV/A

500mV/A

Current range

DC:0A~50A

AC:10A~150Ap-p

DC:50A~500A

AC:150A~1500Ap-p

Output signal error

3%±5mV

1500A:max.4%

Bandwidth(-3dB)

DC~20kHz

Phase shift

DC~65Hz<1.5°

DC~65Hz:<1°

Load impedance

≥1MΩ and ≤100pF

Impedance

0.01Ω

Noise

5mV

Switching rate

0.3V/μS

20mV/μs

Rise time

2.3μs

Measuring condition

23℃±5℃,20~75RH,

Sinusoidal frequency 48~65Hz,external magnetic field <40A/m

No load flow nearby,center testing sample, load impedance1MΩ

Operating voltage

Max.600Vrms

CMRR

Max.600Vrms

Battery

9V

Low battery indicator

with green LED light when >6.5V

Overload indicator

Red LED light indicates the over measuring current, change the range

Mechanical Specifications

Operating temperature

0~+50℃

Storage temperature

-3~+80℃

Temperature influence

Every 10℃,<0.2%

Operating relative humidity

+10℃~+30℃:85±5% relative humidity(non-condensing )

+40℃~+50℃:45±5%relative humidity(non-condensing )

Operating height

0~2000m

Max clam size

Diameter 10.3mm

Dimension

231*36*67mm

Weight

310g(not including battery)

Output

2 meters of coaxial cable, with insulation BNC connector jack at the end
