Product Description
High-frequency current test loop PT-7802/PT-7803
High-frequency current test loop PT-7802/PT-7803 is the passive current tester, with the characteristics of High accuracy,Easy to use and stable performance ,can be used for the altitude-frequency power,Electronic circuit current measurement,output end can directly connect with the voltage meter (True RMS) or oscilloscope for data reading data and observations.
Model |
PT-7802 |
PT-7803 |
accuracy |
0.1(V)/(A)+1%,-0.5% |
0.1(V)/(A)+1%,-0.5% |
Output impedance |
50Ω |
50Ω |
Maximum peak lmpulse Current |
600A |
7500A |
Maximum RMS current |
15A |
80A |
Rise time |
5 nSec. |
20 nSec. |
3db frequency |
25Hz |
1Hz |
3dbHigh-frequency |
60MHz |
20MHz |
output terminal |
BNC |
BNC |
